6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
Specifications
Brand Name :
Dump truck
Model Number :
ZZ3257N3647N1
Certification :
ISO/CCC/SGS
Place of Origin :
China
MOQ :
1 units
Price :
$ 42000-46000
Payment Terms :
T/T or L/C
Supply Ability :
3000 units per month
Delivery Time :
20 days
Packaging Details :
Nude
Product Name :
Tipper truck
Model :
ZZ3257N3647N1
Drive Type :
LHD 6X4
Emission Standard :
Euro 3
Engine :
336-450HP
Cargo Body(CBM) :
17.38
Loading Capacity :
30 tons
Cabin :
A7-w
Application :
Transportation
Description

HOWO A7 6 by 4 Euro 2 Tipper Dump truck front lifting 6 wheel dump truck for Base Rock Topsoil Asphalt

Specifications:

Weight Parameter Complete Vehicle Kerb Mass(kg) 12300
Maxim Umperissiblegrossladen Weight(kg) 25000
Gross Combination Weight(kg)
Dimension Parameter External Dimensions(mm) Length 8585,8665
Wide 2496
High 3490
wheelbase(mm) 3825+1350
Minimum Ground Clearance(mm) 315
Performance Parameter Maximum Speed(km/h) 78
Economical Speed(km/h) 58
Maximum Gradability(%) 58
Turning diameter(m) 17.1
Recommended Engine Engine Type D10.27-31,D10.30-31,WD615.92E,WD615.97E
Rated power(kW)/Rev(r/min) 196/1900,211/1900,194/2200,209/2200
Maximum Torque(N*m)/Rev(r/min) 1190/1200-1500,1340/1200-1500,1100/1100-1600,1250/1200-1600
Gear-box HW10,HW12,HW16
Clutch(mm) 430
Rear Axle Type AC16
Speed Ratio 4.77,5.45
Oil Box(L) 300
Chassis Cross-section(mm) 300
Suspension(Front,Back) 10/12,10/-
Tyre 11.00-20,12.00-20,11.00R20,12.00R20

Chassis

Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced subframe all cold riveted cross members

Front suspension:10 semi-elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer

Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake

Service brake: dual circuit compressed air brake

Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels

Auxiliary brake: engine exhaust brake
Electrics

Operating voltage: 24 V, negative grounded

Starter: 24 V, 5.4 Kw

Alternator: 3-phase, 28 V, 1500 W

Batteries: 2 x 12 V, 165 Ah

Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light

Description:

1. Sinotruk dump truck adopt many key technologies both from home and abroad,and it can achieve the best design and be in good conditions.

2. Humanization.easy and convenient to drive,there are many key close to touch,and it save human labors and also can make the drive focus on the driving

3. Low oil consumption.Sinotruk adopt the engine that combin the MAN and steyr technolgoy,it has the perfect oil performance.

Applications:

It is suitable for in normal roads and tough roads, to transport and unload transport, stone, ore, and others loose materials.

Competitive Advantage

1, High technology make the truck much more perfect than other brand trucks!

2, Longer lifespan and low lost which can save you money and make you earn more!

3, High reliability can achieve run effeciency and much more loading!

4, High safety all around make your drive safe!

5, Many measures are taken to make sure the driver can drive easier and much more comfortable!

6, Good reputation both in China and other developing countries!6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt6 wheel Tipper Dump Truck Front Lifting For Base Rock Topsoil Asphalt
