Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Hauler Truck Low Platform Semi Trailer , 3 Axle truck Trailer Low Bed For Road Transportation
Specifications
Brand Name :
HAIZHOU
Model Number :
HZ4257N3247
Certification :
ISO/CCC/SGS
Place of Origin :
China
MOQ :
1pcs
Price :
$12000-30000
Payment Terms :
T/T or western Union
Supply Ability :
3,000pcs per month
Delivery Time :
20 working days after received your payment
Packaging Details :
Nude
Product Name :
Semi trailer
Payload :
50-100TONS
Application :
Equipment And Bulk Cargo Transportation
Axles No. :
3 Axles
Material :
High Strength Steel Material
advantage :
Customized Design
Standard :
ISO/CCC/SGS
color :
Optional
Description

Hauler Truck Low Bed Trailer 3 Axles 80 Tons for road transportation with warranty

Specifications:

Main specification
Type Lowbed Semi Trailer
Overall dimension 17000*3000*1190
Loading weight 60ton---100ton
Main beam T700, upper plate is 20mm,down plate is 25mm,middle plate is 14mm.
Side beam 30# Steel
Chassis
Traction pin 90# or 50#
Land gear Jost 28ton
Axle 3x20ton
Axle brand FUWA
Suspension type Normal suspension
Laeaf spring 10/10/10
Tire Triangle Brand, 1200R20, 12 sets
Frame
platform thickness 5mm Checked Steel
Accessories
Brake 6 Double-chambers
Tool box 1 unit
Spare wheel carrier 2 units
Side marker lamp LED type
Voltage 24V
Receptacle 7ways (7 wire harness)


Description:

We are direct manufacturer and we have strong producing capacity and R&D capacity!
Frame body Q345B high strength structure steel, automatic submerged arc welding throughout beams, and other cross-section main stringers structure for optimum carrying effect.

Applications:

Apply to transport longer larger parts, miscellaneous pieces of cargo, large components and equipment.

Competitive Advantage:

1. Frame overall spray primer treatment, paint spraying fine surface quality of maritime anti-corrosion standards.
2. Products fully comply with relevant national standard GB1589, GB/T6420, at the same time to meet the individual needs of customers.
3. We can be design the special model according to your requirement.

Warranty

ITEM NAME WARRANTY ITEM NAME WARRANTY
MAIN FRAME FRAME 1 YEAR RUNNING GEAR AXLE 6 MONTHS
SUSPENSION 6 MONTHS AXLE BEARING 3 MONTHS
KING PIN 1 YEAR WHEEL HUB 3 MONTHS
BALANCE ARM 3 MONTHS TIRE 6 MONTHS
ITEM NAME WARRANTY ITEM NAME WARRANTY
BRAKING DEVICE BRAKE DRUM 3 MONTHS SUPPORT DEVICE LANDING GEAR 6 MONTHS
BRKE CHAMBER 3 MONTHS SPARE WHEEL CARRIER 6 MONTHS
AIR RESERVOIR 6 MONTHS
ITEM NAME WARRANTY
OTHERS LEAF SPRING 3 MONTHS
BRAKE CHAMBER DIAPHRAGM 3 MONTHS
EMERGENCY RELAY VALVE 3 MONTHS
BRAKE SHOE 3 MONTHS
RELAY VALVE 3 MONTHS
