UL21031 Integrated EMS Supplied Cable PUR Jacket Rated 80C 125V
UL21031 Integrated EMS Supplied Cable PUR Jacket Rated 80C 125V
Specifications
Brand Name :
WCH Cable
Model Number :
UL21031
Certification :
UL, Cul, AWM
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD 0.123 per meter
Payment Terms :
D/P, T/T, L/C, D/A, Western Union, MoneyGram
Supply Ability :
3,000,000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
305 meters per reel or spool
Style Number :
UL21031
Feature :
Integrated EMS Supplied
Rated Voltage :
125V
Conductor :
Extremely High Purity Copper
Rated Temperature :
60°C or 80°C
Insulation :
PP, SR-PVC, FRPE, HDPE, TPE, TPU
Shield :
Optional
Jacket :
Polyurethane PUR
Description

UL21031 Integrated EMS Supplied Cable PUR Jacket Rated 80C 125V

Approval Style Number: UL21031

Application: interal wiring and external interconnection.

Sheathed material: quality polyurethane PUR

Rated: 60, 80C Degrees, 125V

Style Number Core Quantity Copper Conductor Insulation Thickness Insulation Diameter Shield Coverage Jacket Thickness Overall Diameter Conductor Resistance
AWG No/mm mm mm % mm mm Ω/KM
UL21031 2C 30 7/0.100 0.23 0.80 ≥65 0.76 3.60 381.00
2C 28 7/0.127 0.23 0.90 ≥65 0.76 3.90 239.00
2C 26 7/0.16 0.23 1.00 ≥65 0.76 4.00 150.00
2C 24 11/0.16 0.23 1.10 ≥65 0.76 4.20 94.20
2C 22 17/0.16 0.23 1.30 ≥65 0.76 4.60 59.40
2C 20 21/0.178 0.23 1.50 ≥65 0.76 5.00 36.70
2C 18 34/0.178 0.23 1.80 ≥65 0.76 5.60 23.20
2C 16 26/0.25 0.23 2.00 ≥65 0.76 7.80 14.60
3C 30 7/0.100 0.23 0.80 ≥65 0.76 5.50 381.00
3C 28 7/0.127 0.23 0.90 ≥65 0.76 5.70 239.00
3C 26 7/0.16 0.23 1.00 ≥65 0.76 5.90 150.00
3C 24 11/0.16 0.23 1.10 ≥65 0.76 6.10 94.20
3C 22 17/0.16 0.23 1.30 ≥65 0.76 6.50 59.40
3C 20 21/0.178 0.23 1.50 ≥65 0.76 7.00 36.70
3C 18 34/0.178 0.23 1.80 ≥65 0.76 7.60 23.20
4C 30 7/0.100 0.23 0.80 ≥65 0.76 5.70 381.00
4C 28 7/0.127 0.23 0.90 ≥65 0.76 5.90 239.00
4C 26 7/0.16 0.23 1.00 ≥65 0.76 6.20 150.00
4C 24 11/0.16 0.23 1.10 ≥65 0.76 6.50 94.20
4C 22 17/0.16 0.23 1.30 ≥65 0.76 6.90 59.40
4C 20 21/0.178 0.23 1.50 ≥65 0.76 7.40 36.70
5C 30 7/0.100 0.23 0.80 ≥65 0.76 6.00 381.00
5C 28 7/0.127 0.23 0.90 ≥65 0.76 6.30 239.00
5C 26 7/0.16 0.23 1.00 ≥65 0.76 6.40 150.00
5C 24 11/0.16 0.23 1.10 ≥65 0.76 6.80 94.20
5C 22 17/0.16 0.23 1.30 ≥65 0.76 7.40 59.40
6C 30 7/0.100 0.23 0.80 ≥65 0.76 6.40 381.00
6C 28 7/0.127 0.23 0.90 ≥65 0.76 6.70 239.00
6C 26 7/0.16 0.23 1.00 ≥65 0.76 7.00 150.00
6C 24 11/0.16 0.23 1.10 ≥65 0.76 7.30 94.20

WCH Cable - Professional Manufacturer of PUR cable, FEP cable, PVC cable, Rubber cable

UL21031 Integrated EMS Supplied Cable PUR Jacket Rated 80C 125V

Style Number: UL21031
Rated Grade: 60, 80 deg C, 125 Vac, Cable flame.
Conductor: Above 99.99% High purity copper wires
Screen Shield: Optional
Jacket: Extruded Polyurethane PUR
Average thickness: 30 mils (Ref.)
Minimum thickness: 24 mils (Ref.)
Specification: Detailed specification is to be customized per customer's requirement.
Executed Standard: Appliance Wiring Material UL 758.
Application: Internal wiring and external interconnection of electronic equipment and appliances.
Manufacturer: WCH Cable Industrial Co., Ltd.
Manufacture Location: Dongguan, Guangdong, China
Other Name of the Cable: UL Cable, PUR Cable, Factory Cable, China Cable, UL21031
