Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame
Specifications
Brand Name :
WCH Cable
Model Number :
21118
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD 0.15 per meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000000 meter per Month
Delivery Time :
9 days for ready goods
Packaging Details :
305 meters per reel
Application :
Class 2 Circuits
UL Style Number :
21118
Rated Temperature :
80°C
Jacket Type :
FRPE, FR-PE
Rated Voltage :
30V
Advantage :
Dongguan Made
Description

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Conductor: High Purity of Copper Wire, Stranded or Solid.

Insulation: HDPE, XLPE, FRPE, PP

Jacket: Extruded FRPE

Rated Temperature: 80C

Rated Voltage: 30V

Flame Retardant Grade: VW-1, FT-1, FT-2

Executed Standard: Appliance Wiring Material UL758.

Application: Internal wiring of appliances and external interconnection of electronic equipment.

UL Style Number Core Quantity Conductor Size Conductor Strands Insulation Thickness Insulation Diameter Jacket Thickness Overall Diameter Conductor Resistance
AWG No/mm mm mm mm mm Ω/KM
21118 2C 30 7/0.100 0.23 0.80 0.38 3.20 381.00
2C 28 7/0.127 0.23 0.90 0.38 3.40 239.00
2C 26 7/0.16 0.23 1.00 0.38 3.60 150.00
2C 24 11/0.16 0.23 1.10 0.38 3.80 94.20
2C 22 17/0.16 0.23 1.30 0.38 4.20 59.40
2C 20 21/0.178 0.23 1.50 0.38 4.60 36.70
2C 18 34/0.178 0.23 1.80 0.38 5.20 23.20
2C 16 26/0.25 0.23 2.00 0.38 5.80 14.60
3C 30 7/0.100 0.23 0.80 0.38 3.40 381.00
3C 28 7/0.127 0.23 0.90 0.38 3.50 239.00
3C 26 7/0.16 0.23 1.00 0.38 3.80 150.00
3C 24 11/0.16 0.23 1.10 0.38 4.00 94.20
3C 22 17/0.16 0.23 1.30 0.38 4.40 59.40
3C 20 21/0.178 0.23 1.50 0.38 4.80 36.70
3C 18 34/0.178 0.23 1.80 0.38 5.50 23.20
4C 30 7/0.100 0.23 0.80 0.38 4.80 381.00
4C 28 7/0.127 0.23 0.90 0.38 5.10 239.00
4C 26 7/0.16 0.23 1.00 0.38 5.30 150.00
4C 24 11/0.16 0.23 1.10 0.38 5.50 94.20
4C 22 17/0.16 0.23 1.30 0.38 6.00 59.40
4C 20 21/0.178 0.23 1.50 0.38 6.50 36.70
5C 30 7/0.100 0.23 0.80 0.38 5.00 381.00
5C 28 7/0.127 0.23 0.90 0.38 5.30 239.00
5C 26 7/0.16 0.23 1.00 0.38 5.60 150.00
5C 24 11/0.16 0.23 1.10 0.38 5.80 94.20
5C 22 17/0.16 0.23 1.30 0.38 6.40 59.40
6C 30 7/0.100 0.23 0.80 0.38 5.30 381.00
6C 28 7/0.127 0.23 0.90 0.38 5.60 239.00
6C 26 7/0.16 0.23 1.00 0.38 5.90 150.00
6C 24 11/0.16 0.23 1.10 0.38 6.20 94.20


Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Class 2 Circuits LSZH Cable UL AWM Style 21118, Rated 80C 30V, Cable Flame

Tag: LSZH cable, halogen free cable
