Specifications
Brand Name :
WCH Cable
Model Number :
UL2468
Certification :
UL, CUL, CSA, AWM
Place of Origin :
Dongguan, China
MOQ :
610 meters
Price :
0.12 per meter
Payment Terms :
D/P, L/C, D/A, D/A, T/T, Western Union, MoneyGram
Supply Ability :
500,000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
152.5 meters per reel
UL Style :
2468
Gauge :
26AWG
Material :
PVC
Conductor :
High purity copper wire strands
Rated Temperature :
80°C
Rated Voltage :
300V
Pitch :
1.40mm, 2.0mm, 2.54mm
Feature :
RoHS & Reach Compliant
Description

80C 300V PVC Flat Ribbon Cable UL2468 AWG26 PH1.40 PH2.0, PH2.54 RoHS & Reach Compliant

Style Description: UL2468, Flat Cable, Flat Ribbon Cable, PVC Flat Cable

Rating: 80 deg C, 300 Vac, Horizontal flame. Optional - 60 or 80 deg C Oil.

Insulation Material: Extruded PVC.

Standard: Appliance Wiring Material UL 758.

Application: Internal wiring.

Approval Style Number Cores Conductor Number of Conductor Pitch Insulation Thickness Overall Diameter Conductor
Resistance
NO AWG mm mm mm Ω/KM
UL2468 2 26 7/0.16 1.40 0.45 1.4×2.9 150.00
26 7/0.16 2.00 0.45 1.4×3.4 150.00
26 7/0.16 2.54 0.45 1.4×3.9 150.00
3 26 7/0.16 1.40 0.45 1.4×4.4 150.00
26 7/0.16 2.00 0.45 1.4×5.4 150.00
26 7/0.16 2.54 0.45 1.4×6.4 150.00
4 26 7/0.16 1.40 0.45 1.4×5.9 150.00
26 7/0.16 2.00 0.45 1.4×7.4 150.00
26 7/0.16 2.54 0.45 1.4×8.9 150.00
5 26 7/0.16 1.40 0.45 1.4×7.4 150.00
26 7/0.16 2.00 0.45 1.4×9.4 150.00
26 7/0.16 2.54 0.45 1.4×11.4 150.00
6 26 7/0.16 1.40 0.45 1.4×8.9 150.00
26 7/0.16 2.00 0.45 1.4×11.4 150.00
26 7/0.16 2.54 0.45 1.4×13.9 150.00
7 26 7/0.16 1.40 0.45 1.4×10.4 150.00
26 7/0.16 2.00 0.45 1.4×13.4 150.00
26 7/0.16 2.54 0.45 1.4×16.4 150.00
8 26 7/0.16 1.40 0.45 1.4×11.9 150.00
26 7/0.16 2.00 0.45 1.4×15.4 150.00
26 7/0.16 2.54 0.45 1.4×18.9 150.00
9 26 7/0.16 1.40 0.45 1.4×13.4 150.00
26 7/0.16 2.00 0.45 1.4×17.4 150.00
26 7/0.16 2.54 0.45 1.4×21.4 150.00
10 26 7/0.16 1.40 0.45 1.4×14.9 150.00
26 7/0.16 2.00 0.45 1.4×19.4 150.00
26 7/0.16 2.54 0.45 1.4×23.9 150.00
11 26 7/0.16 1.40 0.45 1.4×16.4 150.00
26 7/0.16 2.00 0.45 1.4×21.4 150.00
26 7/0.16 2.54 0.45 1.4×26.4 150.00
12 26 7/0.16 1.40 0.45 1.4×17.9 150.00
26 7/0.16 2.00 0.45 1.4×23.4 150.00
26 7/0.16 2.54 0.45 1.4×28.9 150.00
13 26 7/0.16 1.40 0.45 1.4×19.4 150.00
26 7/0.16 2.00 0.45 1.4×25.4 150.00
26 7/0.16 2.54 0.45 1.4×31.4 150.00
14 26 7/0.16 1.40 0.45 1.4×20.9 150.00
26 7/0.16 2.00 0.45 1.4×27.4 150.00
26 7/0.16 2.54 0.45 1.4×33.9 150.00
15 26 7/0.16 1.40 0.45 1.4×22.4 150.00
26 7/0.16 2.00 0.45 1.4×29.4 150.00
26 7/0.16 2.54 0.45 1.4×36.4 150.00
