Specifications
Brand Name :
WCH Cable
Model Number :
UL21016 AWG30 PH0.75 BLK+WHT
Certification :
UL Certificate
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD 0.1586 per meter
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
5,000,000 meters per month
Delivery Time :
9 days for ready goods
Packaging Details :
152.5 meters or 305 meters per reel, optional
UL Style :
21016
Gauge :
30AWG
Pitch Distance :
0.75mm
Pin Quantity :
6 Pins
Colour :
Black Colour with White Marking
Conductor Type :
Tinned Stranded Copper Wire
Description

XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1

XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1

WCH Cable - Professional Manufacturer of Ribbon Cable, UL Cord, Cable Assembly

Technical Parameters
Conductor Cores Number 　 6 Pins
Specification (AWG) 30
Section Area (mm²) 0.055
Material 　 Tinned stranded copper
Configuration (mm) TS7/0.10±0.008
Stranded Diameter (mm) 0.30
Width (mm) 4.50±0.30
Insulation Ave Thickness (mm) 0.21
Min Thickness (mm) 0.18
Over Diameter (mm) 0.75±0.10
Material 　 XL-PE (RoHS)
Colour 　 Black with White Marking
Electrical
Capability		 Rated Temperature (℃) 105
Rated Voltage (V) 300
Conductor Resistance (Ω/KM 20℃) 381.0
Insulation Resistance (MΩ/KM 20℃) 100
Other
Properties		 Fire Retardance 　 VW-1
UL Style Number 　 21016
Environmental Standard 　 Lead Free
　 　 RoHS & Reach Compliant

XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1

XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1XLPE Flat Ribbon Cable UL21016 #30AWG 6Pins 0.75mm Pitch VW-1

Tag: UL21016, UL21016 XLPE cable, XLPE Flat Ribbon Cable
