105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
Specifications
Brand Name :
WCH Cable
Model Number :
UL2651-UL2678
Certification :
UL2651
Place of Origin :
Dongguan, China
MOQ :
1220 meters
Price :
USD0.03-0.32 per meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5,000,000 meters per Month
Delivery Time :
9 days for ready goods
Packaging Details :
305 meters per reel
Rated Temperature :
105C
Rated Voltage :
300V
Insulation Material :
PVC
Jacket Material :
PVC
UL Style :
UL2651
Pitch :
1.27mm
Description
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
105C 300V Special PVC Sheathed Round Flat Ribbon Cable Aluminum Foil Screened
Conductor: High Purity Copper Wire
Rated temperature: 105C
Rated voltage: 300V
Insulation: Eco-friendly PVC
Jacket: Eco-friendly PVC
Feature: UL & CSA Approval, RoHS Guaranteed.
Reference Standard: UL758, UL1581, CSA22.2.
Style Number: UL2651
Manufacturer: WCH Cable Industrial Co., Ltd.
Origin: Dongguan, China
Custom Make Service is Available.
Please consult our customer service for discussion of what you like.

WCH Cable - Professional Manufacturer of Ribbon Cable, UL Cord, Cable Assembly

Technical Parameters
Conductor Cores Number 　 16 Pins
Specification (AWG) 26
Section Area (mm²) 0.1492
Material 　 Tinned stranded copper
Configuration (mm) TS19/0.10
Stranded Diameter (mm) 0.5035
Insulation Ave Thickness (mm) 0.25
Min Thickness (mm) 0.21
Over Diameter (mm) 0.9~1.0
Material 　 PVC (RoHS)
Colour 　 Grey
Copper Foil Material 　 One-side Copper Foil
Jacket Ave Thickness (mm) 0.80
Min Thickness (mm) 0.64
Over Diameter (mm) 7.0
Material 　 PVC (RoHS)
Colour 　 Blue
Electrical
Capability		 Rated Temperature (℃) 105
Rated Voltage (V) 300
Conductor Resistance (Ω/KM 20℃) 150
Insulation Resistance (MΩ/KM 20℃) 10
Other
Properties		 Fire Retardance 　 VW-1
UL Style Number 　 2651
Environmental Standard 　 Lead Free
　 　 RoHS & Reach Compliant

Tag: Round flat ribbon cable, Special round ribbon cable
