Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C
Specifications
Brand Name :
TYE
Model Number :
TYE-1318C
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Payment Terms :
TT in advance,Western union,moneygram
Supply Ability :
300 pcs/month
Delivery Time :
7-10 working days
Packaging Details :
free-fumigation wooden case
working area :
1300 x 1800 x 300mm (51.2 x 70.8x 11.8")
Spindle :
3KW spindle or bigger
motor :
stepper motor ( optional servo motor)
Rail :
HIWIN square linear rail
Driving mode :
X,Y axis helical driving,Z axis ball screw
control system :
Ncstudio,DSP,Mach3
Description
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle​ TYE-1318C
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle Machine Features:
1. A three-axis linear guide running smoothly, and high precision.
2. Complete machine using seamless welding steel structure, rigid, and no deformation, the dorsal surface lining plate, strength, steel and good.
3. Constant power spindle motor, cutting intensity, high efficiency.
4. The U-disk embedded control system completely offline to work more convenient and flexible.
Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle parameters:
Model TYE -1318C
Working Area 1300*1800*300mm (51.2 x 70.8x 11.8")
Machine Structure
Thick-walled square tube lathe bed
and T-slot table of sectional material
Work Holding By Clamps
Precision 0.0 1 mm
Positioning accuracy 0.0 1 mm
Repeatability 0. 03 mm
Idling Speed 17 ,000mm/min
Working Speed 10 ,000mm/min
Spindle power 3KW water-cooling ,variable speed
Spindle rotating 0-24000rpm
Available Tools φ 3.175~ φ 12.7
Drive System Stepper motor
Working Voltage AC380V ± 30V, 50HZ
Command Code G Code (*.nc, *.mmg, *.u00, etc.), *.eng
Control System NcStudio( DSP,Mach 3 optional)
Compatible Software Compatible with any software generating G code file in Window 98/XP/7
Overall Dimensions 2350*1800*1700

3D CNC Stone engraver machine details:

Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318CStone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C

3D CNC Stone engraver machine Samples:

Stone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318CStone CNC Engraving machine with 1300 x 1800mm work area/4500W water cooling spindle TYE-1318C
