Customized Size 58 Inch Infrared Touch Frame Withstands Severe Environments
Customized Size 58 Inch Infrared Touch Frame Withstands Severe Environments
Specifications
Brand Name :
GreenTouch
Model Number :
GT-IR-TＢ58.0-1
Certification :
CE, FCC, ROHS
Place of Origin :
China
MOQ :
50
Payment Terms :
T/T, MoneyGram
Supply Ability :
10,000pcs per month
Delivery Time :
3-7 working days after received your payment
Packaging Details :
carton
Screen Ratio :
16:9
Communication :
USB 2.0 Full Speed
Average Current :
≤200mA
Touch Screen Size :
58"
Touch Refresh Rate :
≥ 110Hz
Working Voltage :
DC 5.0V±5%
Power Cunsumption :
≤ 1.0W
LED Lifetime :
60000hours
Description

Standard Black 58 Inch Infrared Touch Frame CE , FCC , ROHS Certification

Product Model number
Model number Ratio Outline(mm) Active Area(mm) Thickness(mm) Touch point
GT-IR-TB58.0-1 16:9 1312.4*763.9 1271*722.5 14.0 16

Main specification

Touch Screen Size 58"
Touch Activation Force No pressure required
Luminous Transmission >92%(100% with no glass)
Reported Touch Resolution Without Driver: 32768*32768
Touch Response Time(Multi touch) 10-15ms
Touch Response Time(One touch) 7ms
Minimum Recognition Point Size 4mm*4mm
Touch Object Size Recognition Yes
Interface Socket type USB cable 1.5 m, socket type 5P

Electrical Specification

Touch Refresh Rate ≥ 110Hz
Communication USB 2.0 Full Speed
PowerSupply Mode USB*1
Working Voltage DC 5.0V±5%
Average Current ≤200mA
Power Cunsumption ≤ 1.0W
LED Lifetime 60000hours
Fault-tolerant Able to work if less than 10% non-consecutive sensors are damaged

Environmental Specification

Humidity Up to 90% RH from 0°C to +40°C, non-condensing
Temperature Range Working temperature:-10℃～50℃
Storage temperature:-20℃～60℃
ESD EN 6100-4-2 2008:3 level.4KV contact discharge and 8KV air discharge
Anti-light Interference Excellent

Software Specification

Firmware Upgrade USB Upgrade: Windows 8,Windows 7
Support OS(Multi touch) Windows10,Windows8,Windows7,Andriod
Support OS (One touch) WindowsXP,MacOS.Linux

Products image:

Customized Size 58 Inch Infrared Touch Frame Withstands Severe EnvironmentsCustomized Size 58 Inch Infrared Touch Frame Withstands Severe EnvironmentsCustomized Size 58 Inch Infrared Touch Frame Withstands Severe EnvironmentsCustomized Size 58 Inch Infrared Touch Frame Withstands Severe EnvironmentsCustomized Size 58 Inch Infrared Touch Frame Withstands Severe EnvironmentsCustomized Size 58 Inch Infrared Touch Frame Withstands Severe EnvironmentsCustomized Size 58 Inch Infrared Touch Frame Withstands Severe Environments

Application:

  • TV
  • PC
  • Gaming device
  • Exhibition
  • Education training
  • Pubic query machine
  • Self-service machine
  • Map directory
  • Any interactive machine
  • And more


Customized Size 58 Inch Infrared Touch Frame Withstands Severe Environments

Packing and shipping:

Customized Size 58 Inch Infrared Touch Frame Withstands Severe EnvironmentsCustomized Size 58 Inch Infrared Touch Frame Withstands Severe Environments

Certificate:

Customized Size 58 Inch Infrared Touch Frame Withstands Severe Environments
