Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Specifications
Place of Origin :
Guangdong, China
Brand Name :
EG
Packaging Details :
Standard packaging with carton or wooden box;Inner packaging: packing with bubble bags and filling with foam plastic materials; Outer packaging: packing with serial size of carton or wooden box.
Supply Ability :
100000 Piece/Pieces per Week
MOQ :
2 pieces
Price :
$130/pieces 2-499 pieces
Certification :
CE/FCC/ROHS/ISO9001/ISO14001
Type :
COB
Display Size :
Customized size
Products Status :
Stock
Touch points :
10 Points
Structures :
Glass/Glass
Cover Outline Dimension :
444.4*291.3 mm
Touch Panel View Area :
410.4*256.5 mm
Touch Panel Active Area :
411.4*157.5 mm
Total Thickness :
14.2 mm
Display P/N :
M190PW01 V8
Interface :
USB/RS232
Operating System :
Win 8/10 android linux
Port :
Guangzhou port/ Shenzhen port,China
Description

19 Inch Touch Display Panel Anti-Glare Touch Screen For Medical Applications Utilizes anti-glare technology to provide clear display in various lighting conditions perfect for medical equipment

Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface

Touch Panel P/N EG-19-A-1610V1
Display P/N M190PW01 V8
Screen Diagonal 19/16:10 inch
Cover Outline Dimension 444.4*291.3 mm
Touch Panel View Area 410.4*256.5 mm
Touch Panel Active Area 411.4*157.5 mm
Touch Panel Thickness 2.9mm
Display Outline Dimension 428*278 mm
Display Active Area 408.24*255.16 mm
Display Thickness 10.3 mm
Total Thickness 14.2 mm
Impact resistance ≥IK07
Luminance, white 500 Typ.Cd/m2
Operation Conditions 20%~90% -30℃ ~ 80℃
Touch Response Time ≤25 ms
Pixels H×V 1440x3(RGB) x 900 pixel
Pixel Pitch 283.5 (per one triad) ×283.5 um


Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 InterfaceMedical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface

Shape:Standard/Customization Material:Glass,Film Optical Bonding
Color:Silkprinting,logo FPC:Shape Design Optional Air Bonding
Glass material:Glass,PMMA IC:EETI/ILITEK LCD:LED,OLED,TFT,IPS
Treatment:AR/AF/AG/Anti-UV Interface:12C/USB/RS232
Thickness:1.1-12mm

Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface
Medical 19 Inch Touch Panel Screen Anti Glare With USB RS232 Interface

  • How can we guarantee quality?

    All products must pass 5 times QC inspection with 100% appearance& Function test on each piece.
  • Which operating systems does is support?

    Our products support Windows,Android,Mac,Linux and Chrome.
  • What are the advantages of our products?

    High precision,response quickly,good quality control,excellent after-service.
  • What is included in your products?

    Touch panel+LCD display+Air bonding/Optical bonding+Controller board+USB Cable.(AD borad and display cables are optional)
  • Do you support sample testing?

    Yes,We can provide standard model in stock or customized sample in 3-7 days for testing purpose.
