Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Specifications
Place of Origin :
Guangdong, China
Brand Name :
EG
Packaging Details :
Standard packaging with carton or wooden box;Inner packaging: packing with bubble bags and filling with foam plastic materials; Outer packaging: packing with serial size of carton or wooden box.
Supply Ability :
1000000 Piece/Pieces per Month
MOQ :
2 units
Price :
$146.00/units 2-499 units
Certification :
CE/FCC/ROHS/ISO9001/ISO14001
Model Number :
EG-17.3-A-0504V1
Type :
COB
Display Size :
customized size
Resolution :
1280 × 3(RGB) × 1024
Size :
17.3 inch
Product Name :
Touch display module
Interface :
USB, RS232, I2C
Application :
POS terminal,Industrial Application
Operating System :
WindowsXP/7/8,Android,Linux,Mac
Ratio aspect :
16:9/16:10/5:4
Touch points :
1-10 point touch
Color :
Black,White,Transparent,colors optional
Brightness :
300cd/m2
Port :
Guangzhou port/ Shenzhen port,China
Description

17.3 Inch Screen Industrial Embedded Open Frame Tft Lcd Panel HMI Touch Monitor With Metal Case For Automation Apply

Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch

Touch Panel P/N EG-17.3-A-0504V1
Display P/N G1703EG01_V1
Screen Diagonal 17.3/5:4 inch
Cover Outline Dimension 372.92*305.34 mm
Touch Panel View Area 337.92*270.34 mm
Touch Panel Active Area 338.92*371.34 mm
Display Outline Dimension 358.5*296.5 mm
Display Active Area 337.92*270.34 mm
Total Thickness 21.9 mm
View angle 89/89/89/89, Full view angle
Cover surface hardness ≥6 H
Impact resistance ≥IK07
Luminance, white 400cd/m2
Operation Conditions 20%~90% RH
Storage Conditions 20%~70% RH
Touch Response Time ≤25 ms
Pixels H×V 1280 × 3(RGB) × 1024
Pixel Pitch 0.264(per one triad) × 0.264 mm


Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 InchIndustrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch

Shape:Standard/Customization Material:Glass,Film Optical Bonding
Color:Silkprinting,logo FPC:Shape Design Optional Air Bonding
Glass material:Glass,PMMA IC:EETI/ILITEK LCD:LED,OLED,TFT,IPS
Treatment:AR/AF/AG/Anti-UV Interface:12C/USB/RS232
Thickness:1.1-12mm

Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch
Industrial TFT Open Frame LCD Panel , Embedded Touch Screen Monitor 17.3 Inch

  • How can we guarantee quality?

    All products must pass 5 times QC inspection with 100% appearance& Function test on each piece.
  • Which operating systems does is support?

    Our products support Windows,Android,Mac,Linux and Chrome.
  • What are the advantages of our products?

    High precision,response quickly,good quality control,excellent after-service.
  • What is included in your products?

    Touch panel+LCD display+Air bonding/Optical bonding+Controller board+USB Cable.(AD borad and display cables are optional)
  • Do you support sample testing?

    Yes,We can provide standard model in stock or customized sample in 3-7 days for testing purpose.
