High Power 573Nm AC Dynamometer& Electric Dyno For Diesel Engine Test
High Power 573Nm AC Dynamometer& Electric Dyno For Diesel Engine Test
Specifications
Brand Name :
SEELONG
Model Number :
SSCD160-1000/3500
Certification :
CMC
Place of Origin :
China Luoyang
MOQ :
1
Price :
Confidential
Payment Terms :
T/T
Supply Ability :
5 sets per month
Delivery Time :
8-12 weeks
Packaging Details :
1200mmX2000mmX1800mm wooden box per set
Power :
160KW
Rated torque :
1528Nm
Max working speed :
3500rpm
Constant power range :
1000--3000rpm
Constant torque range :
0--1000rpm
Measurement accuracy :
0.05/0.2/0.5
Description

High Power 573Nm AC Dynamometer& Electric Dyno For Diesel Engine Test

Product feature

  • Power feedback to grid, energy saving and environmental protection;
  • Bi-directional load, Excellent loading characteristics;
  • Famous brand torque flange, high reliability.

Working principle

Common applications for AC dynamometer (transient electric AC dyno) includes high speed and general purpose applications, automotive, aircraft or aerospace, chain or belt drives, gearboxes, fluid power systems, gas or diesel engines, industrial, marine, transmissions and turbines. AC dynamometer (transient electric AC dyno) or high speed dynamometer typically has speed and power feedback for performance testing and monitoring. Typical features include encoders or other speed or position sensors, torque arms and various types of sensors. AC dynamometer interface includes integrated console, independent console, computer, etc.

The general functions of AC dynamometer include PID control, data acquisition or recording, alarms, power analysis and engine exhaust analysis. The transient electric AC dyno, including air cooled and water cooled dynamometer, are well suited for any types of development and function tests of engine, transmission, powertrain, high speed e-drive and e-motor using in plug-in hybrid, range extender or pure electric vehicles. The test bench application ranges from simple steady state operation up to sophisticated tests with transient and dynamic test cycles.

Characteristic curve

High Power 573Nm AC Dynamometer& Electric Dyno For Diesel Engine Test
