ETH rods 1.4301 AISI 304 seamless cold finished ground stainless steel tube
ETH rods 1.4301 AISI 304 seamless cold finished ground stainless steel tube
ETH rods 1.4301 AISI 304 seamless cold finished ground stainless steel tube
ETH rods 1.4301 AISI 304 seamless cold finished ground stainless steel tube
Specifications
Brand Name :
Torich
Model Number :
A269 A213 A312
Certification :
IS09001 ISO14001 TS16949
Place of Origin :
China
MOQ :
0.3tons
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000tons per year
Delivery Time :
5-8 weeks days
Packaging Details :
In woon boxes.
Standard :
ASTM
Technique :
Cold finished
Application :
Hydraulic Cylinder
Section shape :
Round
Length :
Customer's Requirement
Product name :
ETH rods 1.4301 AISI 304 seamless cold finished ground stainless steel tube
Description

ETH rods 1.4301 AISI 304 seamless cold finished ground stainless steel tube

Material :1.4301(ANSI 304)

Tensile strength Rm min 500MPa

Elastric limit Rp0.2 min 200MPa

Tolerance of OD H8 .H9

Tolerance of ID H8 H9

Rod straighness ≤0.2mm/1000mm 0.3mm/1000mm

Size :22X2 283 45X5 70X4.85 85X7.5mm

Length Random length

1.4301 :

Tensile strength σb (MPa) ≥515-1035
Conditional yield strength σ0.2 (MPa) ≥205
Elongation δ5 (%) ≥40
Reduction of area ψ (%) ≥?
Hardness: ≤201HBW; ≤92HRB; ≤210HV
Density (20℃, g/cm³): 7.93
Melting point (℃): 1398~1454
Specific heat capacity (0~100℃, KJ·kg-1K-1): 0.50
Thermal conductivity (W·m-1·K-1): (100℃) 16.3, (500℃) 21.5
Linear expansion coefficient (10-6·K-1): (0~100℃) 17.2, (0~500℃) 18.4
Resistivity (20℃, 10-6Ω·m2/m): 0.73
Longitudinal elastic modulus (20℃, KN/mm2): 193
Product Standards

ETH rods 1.4301 AISI 304 seamless cold finished ground stainless steel tube
