Specifications
Brand Name :
topzy
Model Number :
BH108
Place of Origin :
China
MOQ :
10pcs
Price :
USD1-USD100 per pcs
Payment Terms :
T/T, Western Union, MoneyGram,paypal
Supply Ability :
10000pcs per month
Delivery Time :
3 days after receiving the payment
Packaging Details :
Plastic drum and White box and carton,industrial packaging or as your requirement
Precision Rating :
P0,P2,P3,P4,P5,P6
Noise :
Z1,Z2,Z3
Sample :
Acceptable
Description

Product Show :

Needle Roller Bearing (needle bearing) is a cylindrical roller with roller bearings, relative to its diameter, roller both thin and long. This is called needle roller. Despite having a smaller cross-section, has a higher load bearing capacity, equipped with a thin and long needle bearing roller (roller diameter D≤5mm, L / D≥2.5, L is the length of the roller), so radial structure is compact, its diameter size and load capacity and other types of bearings, minimum diameter, especially for radial dimensions limited support structure.

BH108 BH1010 BH1012 BH1016 Single Row Full Complement Inch Needle Roller BearingBH108 BH1010 BH1012 BH1016 Single Row Full Complement Inch Needle Roller BearingBH108 BH1010 BH1012 BH1016 Single Row Full Complement Inch Needle Roller Bearing

Needle bearings Specification

Shaft

Diameter

Bearing Designation and mass approx Boundary Dimensions Basic Load Rating Limiting
Open end Closed end ID OD Height Dynamic Static
mm mm mm N N rpm
6.35 B-44 M-441 6.35 11.11 6.35 566 531 10000
B-45 M-451 6.35 11.11 7.92 768 786 10000
B-47 M-471 6.35 11.11 11.13 1210 1410 10000
7.94 B-55 M-551 7.94 12.7 7.92 883 985 8300
B-56 -- 7.94 12.7 9.52 1140 1370 8300
B-57 M-571 7.94 12.7 11.13 1390 1770 8300
B-59 -- 7.94 12.7 14.27 1850 2550 8300
BH-57 -- 7.94 14.29 11.13 1530 1590 11000
BH-59 -- 7.94 14.29 14.27 2080 2340 11000
9.52 B-65 M-651 9.52 14.29 7.92 984 1180 7100
B-66 M-661 9.52 14.29 9.52 1280 1650 7100
B-67 -- 9.52 14.29 11.13 1550 2120 7100
B-68 M-681 9.52 14.29 12.7 1810 2590 7100
B-69 -- 9.52 14.29 14.27 2070 3070 7100
B-610 M-6101 9.52 14.29 15.88 2310 3530 7100
BH-68 -- 9.52 15.88 12.7 2050 2380 9400
11.11 B-76 -- 11.11 15.88 9.52 1390 1930 6300
B-77 -- 11.11 15.88 11.13 1700 2480 6300
B-78 M-781 11.11 15.88 12.7 1980 3030 6300
B-710 -- 11.11 15.88 15.88 2520 4130 6300
BH-78 -- 11.11 17.46 12.7 2260 2780 8300
12.7 B-85 -- 12.7 17.46 7.92 1160 1580 5500
B-86 M-861 12.7 17.46 9.52 1500 2200 5500
B-87 M-871 12.7 17.46 11.13 1830 2840 5500
B-88 M-881 12.7 17.46 12.7 2130 3460 5500
B-810 M-8101 12.7 17.46 15.88 2720 4720 5500
B-812 M-8121 12.7 17.46 19.05 3260 5980 5500
BH-87 -- 12.7 19.05 11.13 2060 2550 7500
BH-88 -- 12.7 19.05 12.7 2450 3180 7500
BH-810 -- 12.7 19.05 15.88 3180 4440 7500
BH-812 -- 12.7 19.05 19.05 3850 5690 7500
14.29 B-95 M-951 14.29 19.05 7.92 1240 1780 5000
B-96 -- 14.29 19.05 9.52 1600 2480 5000
B-97 -- 14.29 19.05 11.13 1950 3190 5000
B-98 -- 14.29 19.05 12.7 2280 3900 5000
B-910 -- 14.29 19.05 15.88 2900 5310 5000
B-912 M-9121 14.29 19.05 19.05 3480 6730 5000
BH-98 -- 14.29 20.64 12.7 2630 3580 6800
BH-910 -- 14.29 20.64 15.88 3400 5000 6800
BH-912 -- 14.29 20.64 19.05 4130 6410 6800
15.88 B-105 -- 15.88 20.64 7.92 1310 1980 4500
B-107 M-1071 15.88 20.64 11.13 2070 3550 4500
B-108 M-1081 15.88 20.64 12.7 2410 4330 4500
B-1010 -- 15.88 20.64 15.88 3070 5900 4500
B-1012 M-10121 15.88 20.64 19.05 3690 7480 4500
BH-108 MH-1081 15.88 22.22 12.7 2790 3890 6200
BH-1010 -- 15.88 22.22 15.88 3620 5530 6200
BH-1012 -- 15.88 22.22 19.05 4390 7130 6200
BH-1016 -- 15.88 22.22 25.4 5830 10300 6200

Our factory:

Anhui Topzy Bearing import&export Co., Ltd. is Specializing in production the bearings , our bearing are widely used by big mechanical corporations. Topzy bearing has high-quality management team,experienced pratitioners,and quick response and professional service team,

and meanwhile is equipped with first-class automatic production lines as well as complete quality management machines and system.

We sincerely hope to establish a good business relationship with you in The future.

Our advantages:

1. Manufacturer,the most competive price and good quality

2. Perfect group of technical engineers give you the best support

3.Well-trained group of international sales provide the best service

4.OEM brand aviliable

5.Rich stock and quick delivery

QC:

We have complete process for the production and quality assurance to make sure our products can meet your requirement. And our quality can compare with the most chinese famous bearing manufacture. we have the same technology. Such as
1. Assembly
2. Windage test
3. Cleaning
4. Rotary test
5. Greasing and gland
6. Noise inspection
7. Appearance inspection
8. Rust prevention
9. Product packaging

Packaging & Shipping

Shipping:

1.small quantity, can delivery by global express: DHL TNT FedEx ARAMEX EMS UPS. this is door to door.

2.large quantity, can delivery by air, by sea, this is port to port.

Payment:

T/T, L/C, Money Gram, Payal, Western Union etc.

Lead Time:

Sample Lead-times: generally 3-5 workdays.
Production Lead-times: 3-5 days after get payment or as contract required

FAQ

Q: Can i customize the bearings?

A: Yes,sure .we provide customize- made service. You need to send us the drawings for our further handing.

Q:Are you a factory or trading company?

A:Anhui Topzy Bearing Co.,Ltd is specialized in manufacturing and exporting Bearing.We have own factory and Warehouse located in Anhui city.

Q:Can I get some samples and do you offer the sample free?

A:Yes, sure, we are honored to offer you samples.If we have stock, we can send you free sample. And you just need to pay freight. If there have no stock, you need to pay sample fee and freight.

Q:Does the sample fee can be return back?

A: If you place an order, we can return part of sample fee even all of fee to you.It also depends on the Quantity of order and the type of sample.

Q:What is the MOQ for bearing?
A: Our MOQ is 1 pc.
