Three Head Automatic Dry Type Transformer Coil Winding Machine 2000kg 0-200rpm 7.5KW
Three Head Automatic Dry Type Transformer Coil Winding Machine 2000kg 0-200rpm 7.5KW
Specifications
Winding Shaft :
Four-jaw chuck with tail stock
Warranty :
1 Year
Place of Origin :
Shanghai, China
Price :
USD 18600-21500 / Set
Certification :
ISO 9001:2015
Packaging Details :
Export wooden case with protective film and steel strapping
Safety Feature :
Emergency stop and overload protection
Motor Power :
7.5KW
Model Number :
DYJ-009-THR
Wire Diameter Range :
0.3-4.0mm round wire
Winding Speed :
0-200rpm
Max Winding Width :
600mm
Max Transformer Capacity :
1600 kVA
Payment Terms :
T/T, L/C, D/A, D/P
Control System :
PLC and HMI control system
MOQ :
1 Set
Transformer Application :
Dry Type Transformer
Load Capacity :
2000kg
Brand Name :
TONGLI
Delivery Time :
15-30 working days
Supply Ability :
10 Sets per Month
Description

Three Head Automatic Dry Type Transformer Coil Winding Machine

This three head automatic coil winding machine is engineered for the production of dry type transformer coils, delivering precise and repeatable winding for transformer manufacturers worldwide. It handles both copper and aluminum conductors and integrates easily into existing coil production lines.

Key Features

  • Load Capacity: 2000kg maximum coil weight for heavy duty transformer coils
  • Winding Speed: 0-200rpm stepless speed regulation with stable and smooth torque output
  • Motor Power: 7.5KW winding motor for reliable continuous operation
  • Control System: PLC and HMI control system for accurate parameter setting and repeatability
  • Winding Shaft: Four jaw chuck with reinforced tail stock and square shaft for stable coil clamping
  • Safety Design: Emergency stop and overload protection ensure safe operation
  • Wire Compatibility: 0.3-4.0mm round wire supported, copper and aluminum
  • Max Winding Width: 600mm to suit a wide range of coil sizes

Transformer Applications

Suitable for dry type transformer production and widely used for distribution transformers, power transformers, reactors, current transformers and other electrical coil manufacturing.

Why Choose This Machine

The three wire guides design improves winding precision and production efficiency while reducing labor cost. Every unit is inspected before shipment and backed by a 1 year warranty with online technical support and spare parts supply.
