Automatic Layer Transformer Coil Winding Machine 800rpm Programmable Traverse
Automatic Layer Transformer Coil Winding Machine 800rpm Programmable Traverse
Specifications
Price :
USD 8600-13500 / Set
Delivery Time :
15-30 working days after order confirmation
Warranty :
1 Year
Brand Name :
TONGLI
Model Number :
TL-8800L
Supply Ability :
20 Sets per Month
Payment Terms :
T/T, L/C, Western Union
Max Transformer Capacity :
1000 kVA
Place of Origin :
Shanghai, China
Power Supply :
AC 220V/380V 50Hz
Winding Precision :
0.1 turn
Certification :
ISO 9001:2015
Condition :
New
Center Height :
700 mm
Axis Length :
1000 mm
Motor Power :
4 kW
Max Load :
500 kg
Packaging Details :
Export wooden case with steel strapping and shock-proof foam padding
Control System :
PLC
Wire Diameter Range :
0.1-2.5 mm
MOQ :
1 Set
Working Torque :
150 Nm
Winding Speed :
0-800 rpm
Description

Automatic Layer Transformer Coil Winding Machine 800rpm Programmable Traverse

Product Overview

This automatic layer transformer coil winding machine provides 800rpm winding speed with programmable traverse and digital counter for precision layer wound transformer coils.

Key Features

  • Automatic Layer Winding: programmable multi layer winding patterns
  • Programmable Traverse: adjustable traverse width and pitch
  • Digital Counter: precise turn counting with preset function
  • Tension Control: mechanical and electronic tension options
  • Foot Switch Operation: convenient start and stop control
  • Versatile: suitable for small distribution and instrument transformer coils

Transformer Applications

  • Small distribution transformer coil winding
  • Instrument transformer layer winding
  • Control transformer coil production
  • Custom layer wound transformer coils

Technical Specifications

Model NumberTL-8800L
Max Transformer Capacity1000 kVA
Winding Speed0-800 rpm
Wire Diameter Range0.1-2.5 mm
Center Height700 mm
Axis Length1000 mm
Max Load500 kg
Motor Power4 kW
Working Torque150 Nm
Control SystemPLC
Power SupplyAC 220V/380V 50Hz
Winding Precision0.1 turn
ConditionNew
Warranty1 Year

Customization

Winding speed, torque and traverse parameters programmable per transformer coil drawing. Custom center height, axis length and faceplate diameter available for special transformer sizes. Tension control adjustable for copper and aluminum round wire, strip and foil. OEM/ODM accepted: customer brand name, color scheme and control interface.

Packing and Shipping

Packing: Export wooden case with protective film wrapping and steel strapping, shock-proof foam padding inside. Loading: Professional container loading with lifting points marked; machines above 3m are split and reassembled on site. Delivery Time: 15-30 working days after order confirmation. Shipping: Sea, air or express delivery; FOB Shanghai, CIF, CFR and EXW trade terms supported. Documents: Commercial invoice, packing list, bill of lading, certificate of origin and commissioning manual.

Certifications

ISO 9001:2015 certified production line with strict quality control on every machine. One year warranty, free commissioning and training, lifelong spare parts support. Factory direct supply from Shanghai Tongli Electrical Engineering Equipment Factory. Contact us for detailed specifications and quotations.
