Toroidal Transformer Coil Winding Machine 900rpm Shuttle Ring Core Automatic
Toroidal Transformer Coil Winding Machine 900rpm Shuttle Ring Core Automatic
Specifications
Payment Terms :
T/T, L/C, Western Union
Certification :
ISO 9001:2015
Price :
USD 7800-12800 / Set
Core Outer Diameter :
30-350 mm
Model Number :
TL-7900T
Winding Speed :
0-900 rpm
Motor Power :
1.5 kW
Power Supply :
AC 220V 50Hz
MOQ :
1 Set
Wire Diameter Range :
0.05-2.0 mm
Brand Name :
TONGLI
Control System :
PLC
Condition :
New
Place of Origin :
Shanghai, China
Supply Ability :
20 Sets per Month
Delivery Time :
15-30 working days after order confirmation
Packaging Details :
Export wooden case with steel strapping and shock-proof foam padding
Warranty :
1 Year
Max Torque :
80 Nm
Core Inner Diameter :
10-200 mm
Shuttle Type :
Rotating Shuttle
Winding Precision :
0.05 turn
Description

Toroidal Transformer Coil Winding Machine 900rpm Shuttle Ring Core Automatic

Product Overview

This toroidal transformer coil winding machine winds ring core transformer coils at 900rpm shuttle speed with automatic tension and programmable turns.

Key Features

  • Toroidal Design: dedicated shuttle winding for ring core transformer coils
  • High Speed: 900rpm shuttle speed for efficient toroid winding
  • Automatic Tension: constant tension for uniform toroidal winding
  • Programmable Turns: preset turn counter with automatic stop
  • Core Protection: soft start and stop prevents core damage
  • Wide Range: handles toroidal cores from 30mm to 350mm outer diameter

Transformer Applications

  • Toroidal transformer coil winding
  • Ring core transformer production
  • Current transformer toroidal winding
  • Audio transformer toroid winding

Technical Specifications

Model NumberTL-7900T
Core Inner Diameter10-200 mm
Core Outer Diameter30-350 mm
Winding Speed0-900 rpm
Wire Diameter Range0.05-2.0 mm
Shuttle TypeRotating Shuttle
Max Torque80 Nm
Motor Power1.5 kW
Control SystemPLC
Power SupplyAC 220V 50Hz
Winding Precision0.05 turn
ConditionNew
Warranty1 Year

Customization

Winding speed, torque and traverse parameters programmable per transformer coil drawing. Custom center height, axis length and faceplate diameter available for special transformer sizes. Tension control adjustable for copper and aluminum round wire, strip and foil. OEM/ODM accepted: customer brand name, color scheme and control interface.

Packing and Shipping

Packing: Export wooden case with protective film wrapping and steel strapping, shock-proof foam padding inside. Loading: Professional container loading with lifting points marked; machines above 3m are split and reassembled on site. Delivery Time: 15-30 working days after order confirmation. Shipping: Sea, air or express delivery; FOB Shanghai, CIF, CFR and EXW trade terms supported. Documents: Commercial invoice, packing list, bill of lading, certificate of origin and commissioning manual.

Certifications

ISO 9001:2015 certified production line with strict quality control on every machine. One year warranty, free commissioning and training, lifelong spare parts support. Factory direct supply from Shanghai Tongli Electrical Engineering Equipment Factory. Contact us for detailed specifications and quotations.
