Vertical Transformer Coil Winding Machine 1600kVA Cast Resin Coil Automatic Control
Vertical Transformer Coil Winding Machine 1600kVA Cast Resin Coil Automatic Control
Specifications
Working Torque :
900 Nm
Control System :
PLC
Winding Speed :
0-400 rpm
Packaging Details :
Export wooden case with steel strapping and shock-proof foam padding
Axis Length :
1300 mm
Motor Power :
5.5 kW
Supply Ability :
20 Sets per Month
Power Supply :
3-Phase AC 380V 50Hz
Condition :
New
Place of Origin :
Shanghai, China
Brand Name :
TONGLI
MOQ :
1 Set
Certification :
ISO 9001:2015
Price :
USD 14500-21800 / Set
Max Transformer Capacity :
1600 kVA
Winding Precision :
0.1 turn
Model Number :
TL-8160V
Delivery Time :
15-30 working days after order confirmation
Wire Diameter Range :
0.5-5.0 mm
Max Load :
1000 kg
Warranty :
1 Year
Payment Terms :
T/T, L/C, Western Union
Center Height :
900 mm
Description

Vertical Transformer Coil Winding Machine 1600kVA Cast Resin Coil Automatic Control

Product Overview

This vertical transformer coil winding machine is purpose built for 1600kVA cast resin dry type transformer coils with automatic control and precision tension.

Key Features

  • Vertical Axis Design: ideal for cast resin dry type transformer coil winding
  • Automatic Control: programmable winding speed, turns and traverse
  • Precision Tension: stable tension control for uniform coil density
  • Cast Resin Compatible: suitable for epoxy cast coil production
  • Stable Structure: heavy duty vertical column and tailstock
  • Easy Operation: touch screen interface with recipe storage

Transformer Applications

  • Cast resin dry type transformer coil winding
  • Epoxy cast coil production
  • Distribution transformer coil winding
  • Special vertical transformer coil manufacturing

Technical Specifications

Model NumberTL-8160V
Max Transformer Capacity1600 kVA
Winding Speed0-400 rpm
Wire Diameter Range0.5-5.0 mm
Center Height900 mm
Axis Length1300 mm
Max Load1000 kg
Motor Power5.5 kW
Working Torque900 Nm
Control SystemPLC
Power Supply3-Phase AC 380V 50Hz
Winding Precision0.1 turn
ConditionNew
Warranty1 Year

Customization

Winding speed, torque and traverse parameters programmable per transformer coil drawing. Custom center height, axis length and faceplate diameter available for special transformer sizes. Tension control adjustable for copper and aluminum round wire, strip and foil. OEM/ODM accepted: customer brand name, color scheme and control interface.

Packing and Shipping

Packing: Export wooden case with protective film wrapping and steel strapping, shock-proof foam padding inside. Loading: Professional container loading with lifting points marked; machines above 3m are split and reassembled on site. Delivery Time: 15-30 working days after order confirmation. Shipping: Sea, air or express delivery; FOB Shanghai, CIF, CFR and EXW trade terms supported. Documents: Commercial invoice, packing list, bill of lading, certificate of origin and commissioning manual.

Certifications

ISO 9001:2015 certified production line with strict quality control on every machine. One year warranty, free commissioning and training, lifelong spare parts support. Factory direct supply from Shanghai Tongli Electrical Engineering Equipment Factory. Contact us for detailed specifications and quotations.
