Customized Transformer Coil Winding Machine OEM 2000mm Faceplate Diameter

Product Overview

This customized transformer coil winding machine offers OEM configuration with 2000mm faceplate, custom axis length and 5000Nm torque for special transformer coils.

Key Features

• OEM Customization: tailor made to customer coil specifications
• Large Faceplate: 2000mm faceplate for big transformer coils
• Flexible Axis: custom axis length per customer requirement
• High Torque: 5000Nm for heavy wire and strip winding
• PLC Control: programmable winding parameters
• Full Support: engineering support for special transformer coil tooling

Transformer Applications

• Special large transformer coil winding
• OEM transformer coil production
• Custom HV LV coil winding
• Non standard transformer winding

Technical Specifications

Customization

Winding speed, torque and traverse parameters programmable per transformer coil drawing. Custom center height, axis length and faceplate diameter available for special transformer sizes. Tension control adjustable for copper and aluminum round wire, strip and foil. OEM/ODM accepted: customer brand name, color scheme and control interface.

Packing and Shipping

Packing: Export wooden case with protective film wrapping and steel strapping, shock-proof foam padding inside. Loading: Professional container loading with lifting points marked; machines above 3m are split and reassembled on site. Delivery Time: 15-30 working days after order confirmation. Shipping: Sea, air or express delivery; FOB Shanghai, CIF, CFR and EXW trade terms supported. Documents: Commercial invoice, packing list, bill of lading, certificate of origin and commissioning manual.

Certifications

ISO 9001:2015 certified production line with strict quality control on every machine. One year warranty, free commissioning and training, lifelong spare parts support. Factory direct supply from Shanghai Tongli Electrical Engineering Equipment Factory. Contact us for detailed specifications and quotations.
