Silent U7 Linear Actuator For Electric Height Adjustable Desk
Silent U7 Linear Actuator For Electric Height Adjustable Desk
Silent U7 Linear Actuator For Electric Height Adjustable Desk
Silent U7 Linear Actuator For Electric Height Adjustable Desk
Silent U7 Linear Actuator For Electric Height Adjustable Desk
Silent U7 Linear Actuator For Electric Height Adjustable Desk
Specifications
Efficiency :
IE 1
Construction :
Permanent Magnet
Dutycycle :
10%
Limit Switch :
Built-in
Model Number :
U7
Rated Voltage :
12/24v
Position Feedback :
Hall Sensor
Continuous Current(A) :
2.8A
Protect Feature :
Waterproof
Usage :
Electric Height Adjustable Desk
Price :
Negotiable
Torque :
Requests
Type :
Gear Motor
MOQ :
1 piece
Speed(RPM) :
1500r/m
Warranty :
3 months ~ 1 year
Certification :
ce
Protection class :
IP65
Stroke :
50~500mm
Place of Origin :
Guangdong, China
Speed :
full load 6~8mm/s
Commutation :
Brush
Brand Name :
TOMUU
Max. load :
2000N
Description
Silent U7 Linear Actuator for Electric Height Adjustable Desks
TOMUU U7 silent linear actuator serves as the core drive component for household electric lifting desks. With medium thrust capacity of 500-1500N, it provides stable support for desktop surfaces and office equipment. The 12V low-voltage operation ensures safe compliance with household electrical standards, while the ultra-quiet gear mechanism enables silent lifting without noise disruption.
Compact hidden design integrates seamlessly into desk internal structures, featuring stable self-locking functionality to maintain height position and prevent unintended lowering.
Silent U7 Linear Actuator For Electric Height Adjustable Desk
Technical Specifications
Parameter Specification
Voltage 12V DC / 24V DC
Max Load 2000N
Speed 4.7-65mm/s
Duty Cycle 10%
Protection Class IP65/IP66/IP67
Noise Level ≤60dB
Stroke 50-800mm
Material Aluminium Alloy
Product Dimensions
Silent U7 Linear Actuator For Electric Height Adjustable Desk
Key Advantages
  • Ultra-silent lifting technology creates quiet office and study environments, eliminating mechanical noise disturbance
  • Stable self-locking performance ensures long-term height fixation without sliding, enhancing user safety
  • Low-voltage safe drive system eliminates household electrical hazards
  • Slim hidden structure preserves desk aesthetics and leg space
  • Multiple thrust specifications compatible with single and dual motor lifting desk configurations
  • Certified safety standards and durable construction for long-term reliability
