Specifications
Brand Name :
BaseTi
Model Number :
TBC002
Certification :
ISO 13485, CE Certificate
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
12~20 days
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Production standards :
ASTM F67, ASTM F136, ISO 5832
Surface process :
Pickled, Polished, Annealed
Grade :
Grade 1, Grade 2, Grade 4, Grade 5 (Ti6Al4V)
Tolerance :
Thickness: ±0.005mm, Width: ±0.2mm
Rolling process :
Hot Rolling, Cold Rolling
Size :
Thickness 0.01mm - 1mm, Width 20mm - 500mm
Packaging :
Vacuum-sealed packaging to maintain sterility
Description

0.1mm Medical Titanium Foil Biocompatible Materials for Orthopedic, Cardiovascular Stents,Drug Delivery Systems

Medical Titanium Foil - OVERVIEW

*If you have any requirements for customized titanium coil/foil, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

Medical Titanium coil&foil specifications & parameters
Product name 0.01mm0.02mm 0.05 0.08mm
Application field Orthopedic implants, Dental implants, Surgical instruments, Pacemaker casings
Available size Thickness 0.01mm - 1mm, Width 20mm - 500mm
Grade Grade 1, Grade 2, Grade 4, Grade 5 (Ti6Al4V)
Production stadards ASTM F67, ASTM F136, ISO 5832
Tolerance ±0.03mm for thickness, ±0.1mm for width
Rolling process Cold Rolled
Surface process Acid-washing, Polishing, Sandblasting
Delivery time 13-16days
Key Words

Medical Titanium Foil
Biocompatible Materials
Orthopedic Implants
Cardiovascular Stents
Surgical Instruments
Dental Implants
BaseTi Medical Titanium Foil
Drug Delivery Systems

Medical Titanium Foil - SOLUTIONS

Medical Titanium Foil: The Vanguard Material in Healthcare Solutions
When it comes to the diverse applications of materials in the medical field, Medical Titanium Foil has garnered attention for its unmatched properties and compatibility with biological systems. The foil is not only renowned for its strength-to-weight ratio but also for its unique combination of corrosion resistance, biocompatibility, and reduced artifacts in imaging studies. Below, we outline five critical applications where Medical Titanium Foil stands as a revolutionary solution.

  • Implants and Prosthetics

Medical Titanium Foil offers an exemplary strength-to-weight ratio with tensile strength ranging from 30,000 to 200,000 psi, depending on the grade. This makes it an ideal material for orthopedic implants like hip and knee replacements. Moreover, its remarkable biocompatibility ensures minimal inflammation and allergic reactions, promoting quicker healing.

  • Surgical Instruments

High-quality surgical instruments often employ Medical Titanium Foil for its extraordinary corrosion resistance. It stands up to frequent sterilization processes better than most materials, ensuring a long-lasting and reliable toolkit for surgeons.

  • Cardiovascular Stents

Titanium's natural compatibility with the human body makes it a preferred choice for cardiovascular stents. The material reduces the risk of inflammation and offers a more stable option compared to conventional materials like stainless steel. Medical Titanium Foil ensures minimal arterial wall stress due to its mechanical properties, making it ideal for this delicate application.

  • Dental Implants

Dental implants made from Medical Titanium Foil not only offer strength but also are lightweight, reducing the pressure on the jawbone. The material's biocompatibility also minimizes the risk of peri-implantitis, a common complication in dental implants.

  • Drug Delivery Systems

Medical Titanium Foil serves as a barrier material in drug delivery systems like patches or implantable reservoirs. The foil’s inertness ensures no unwanted reactions with the drugs, and its thin profile allows for a controlled rate of release.

  • BaseTi's Medical Titanium Foil

Our brand, BaseTi, supplies Medical Titanium Foil that meets or exceeds international standards such as ASTM F67 and ASTM F136, ensuring that healthcare professionals can rely on our products for the most demanding applications.

Conclusion
Medical Titanium Foil is rapidly becoming a material of choice across a myriad of medical applications, offering solutions that combine mechanical strength, biocompatibility, and durability.

0.1mm Medical  Titanium Foil Sheet Biocompatible Materials For Orthopedic

Physical Properties of Medical Titanium Foil
Grade Density (g/cm³) Melting Point (°C) Boiling Point (°C)
Young's Modulus (GPa)
Thermal Conductivity (W/m·K)
Gr1 4.51 1,668 3,287 116 21.9
Gr2 4.50 1,670 3,280 114 21.8
Gr3 4.49 1,672 3,275 112 21.7
Gr4 4.48 1,675 3,270 110 21.5
Gr5 4.43 1,680 3,265 115 22.0
Chemical Composition of Medical Titanium Foil
Grade Titanium (%) Iron (Fe) Oxygen (O)
Carbon (C)
Nitrogen (N) Hydrogen (H)
Gr1 Bal. ≤ 0.20 ≤ 0.18 ≤ 0.08 ≤ 0.03 ≤ 0.015
Gr2 Bal. ≤ 0.30 ≤ 0.25 ≤ 0.10 ≤ 0.03 ≤ 0.015
Gr3 Bal. ≤ 0.30 ≤ 0.35 ≤ 0.10 ≤ 0.05 ≤ 0.015
Gr4 Bal. ≤ 0.50 ≤ 0.40 ≤ 0.10 ≤ 0.05 ≤ 0.015
Gr5 Bal. ≤ 0.40 ≤ 0.20 ≤ 0.10 ≤ 0.05 ≤ 0.015

Note: BaseTi offer customization to meet your specific chemical composition requirements.
