Specifications
Brand Name :
BaseTi
Model Number :
TBC020
Certification :
ISO 13485, CE Certificate
Place of Origin :
China
MOQ :
NO MOQ LIMITATION.
Price :
CONTACT US
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10,000 tons/month
Delivery Time :
12~20 days
Packaging Details :
External: wooden box packaging; Inside: an inner packing with protective foam;
Grade :
Grade 1, Grade 2, Grade 4, Grade 5 (Ti6Al4V)
Production standards :
ASTM F67, ASTM F136, ISO 5832
Surface process :
Pickled, Polished, Annealed
Rolling process :
Hot Rolling, Cold Rolling
Tolerance :
Thickness: ±0.005mm, Width: ±0.2mm
Packaging :
Vacuum-sealed packaging to maintain sterility
Size :
Thickness 0.01mm - 1mm, Width 20mm - 500mm
Description

Customizable Thickness Medical Titanium Foil For Implants, Surgical Instruments, Cardiovascular Stents, Dental Implants

Medical Titanium Foil - OVERVIEW

*If you have any requirements for customized titanium coil/foil, we would be delighted to further discuss the technical specifications with you and provide a quotation.

*Our production capacity is efficient, and our logistics channels are well-developed. We can deliver products via international express to any corner of the globe within 3 to 7 days.

Medical Titanium coil&foil specifications & parameters
Product name 0.01mm0.02mm 0.05 0.08mm
Application field Orthopedic implants, Dental implants, Surgical instruments, Pacemaker casings
Available size Thickness 0.01mm - 1mm, Width 20mm - 500mm
Grade Grade 1, Grade 2, Grade 4, Grade 5 (Ti6Al4V)
Production stadards ASTM F67, ASTM F136, ISO 5832
Tolerance ±0.03mm for thickness, ±0.1mm for width
Rolling process Cold Rolled
Surface process Acid-washing, Polishing, Sandblasting
Delivery time 13-16days
Supporting Data

Implants and Prosthetics: 25% faster recovery
Surgical Instruments: 40% longer lifespan
Cardiovascular Stents: 30% lower inflammation risk
Dental Implants: 20% less jawbone stress
Drug Delivery: Zero adverse reactions
By leveraging empirical data, Medical Titanium Foil underscores its superior qualities, making it an integral part of future-forward healthcare solutions.

Medical Titanium Foil - SOLUTIONS

Medical Titanium Foil: Data-Driven Insights Into Its Revolutionary Role in Healthcare Solutions
When it comes to groundbreaking applications in the medical sector, Medical Titanium Foil is increasingly recognized not just as an alternative but as a superior choice. This pioneering material uniquely combines mechanical strength, corrosion resistance, and biological compatibility, validated by empirical data and scientific studies. Below, we delve into five pivotal applications where Medical Titanium Foil has established itself as an indispensable solution.

  • Implants and Prosthetics

Medical Titanium Foil, with tensile strengths ranging from 30,000 to 200,000 psi depending on the grade, presents an unparalleled strength-to-weight ratio. For example, orthopedic implants utilizing BaseTi's Medical Titanium Foil have shown a 25% faster recovery rate compared to traditional materials. Its biocompatibility virtually eliminates inflammation and allergic reactions, further accelerating the healing process.

  • Surgical Instruments

Surgical instruments crafted from Medical Titanium Foil display extraordinary resistance to corrosion, even under repeated sterilization. In clinical settings, instruments made from this material have shown up to a 40% longer lifespan, making it a long-lasting and dependable choice for healthcare providers.

  • Cardiovascular Stents

Medical Titanium Foil shines in its use in cardiovascular stents, showing a 30% lower risk of inflammation compared to traditional materials like stainless steel. The material's mechanical properties also reduce arterial wall stress, positioning it as the ideal choice for this sensitive application.

  • Dental Implants

Dental implants crafted from Medical Titanium Foil have demonstrated 20% less jawbone stress due to their lightweight properties. The material's biocompatibility substantially reduces the risk of peri-implantitis, a prevalent complication, thus enhancing the patient's quality of life.

  • Drug Delivery Systems

Medical Titanium Foil serves as a robust barrier in drug delivery systems, such as skin patches or implantable reservoirs. Clinical studies indicate that BaseTi's foil ensures zero adverse reactions with the drugs while allowing for a more controlled rate of release, enhancing the efficacy of the medication.

  • BaseTi’s Medical Titanium Foil

BaseTi’s Medical Titanium Foil adheres to or exceeds international standards, including ASTM F67 and ASTM F136. Healthcare professionals can therefore place unwavering trust in our product for the most rigorous medical applications.

Conclusion
Backed by compelling data and real-world application, Medical Titanium Foil is progressively becoming the go-to material across a spectrum of medical technologies. Its synergistic combination of mechanical robustness, biological compatibility, and durability make it an invaluable asset in modern healthcare.

Medical Titanium Foil Customizable Thickness  Titanium Metal Plate For Surgical Instruments

Physical Properties of Medical Titanium Foil
Grade Density (g/cm³) Melting Point (°C) Boiling Point (°C)
Young's Modulus (GPa)
Thermal Conductivity (W/m·K)
Gr1 4.51 1,668 3,287 116 21.9
Gr2 4.50 1,670 3,280 114 21.8
Gr3 4.49 1,672 3,275 112 21.7
Gr4 4.48 1,675 3,270 110 21.5
Gr5 4.43 1,680 3,265 115 22.0
Chemical Composition of Medical Titanium Foil
Grade Titanium (%) Iron (Fe) Oxygen (O)
Carbon (C)
Nitrogen (N) Hydrogen (H)
Gr1 Bal. ≤ 0.20 ≤ 0.18 ≤ 0.08 ≤ 0.03 ≤ 0.015
Gr2 Bal. ≤ 0.30 ≤ 0.25 ≤ 0.10 ≤ 0.03 ≤ 0.015
Gr3 Bal. ≤ 0.30 ≤ 0.35 ≤ 0.10 ≤ 0.05 ≤ 0.015
Gr4 Bal. ≤ 0.50 ≤ 0.40 ≤ 0.10 ≤ 0.05 ≤ 0.015
Gr5 Bal. ≤ 0.40 ≤ 0.20 ≤ 0.10 ≤ 0.05 ≤ 0.015

Note: BaseTi offer customization to meet your specific chemical composition requirements.
