Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Titanium Grade 9 Gr5 Alloy Rod ASTM B348 For Industry Aerospace
Specifications
Brand Name :
Changsheng
Model Number :
DIN
Certification :
ISO 9001
Place of Origin :
CHINA
MOQ :
50kg
Price :
15usd/kg
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
7-10 days
Packaging Details :
film and wooden case,carton Packaging can be according to customer requirements.
Supply Ability :
5000 Kilogram/Kilograms per Month
Materials :
titanium
Grade :
Grade 1,Grade 5, ti-6al-4v,grade 2,grade 4,grade 23,grade 7,grade 11
Diameter :
3-600mm
Surface :
Polished, Pickling
MOQ :
50KG
Standard :
ASTM B348,AMS 4904,ASTM F67,ASTM F136
Technical :
Forged
Description

Description

Titanium Grade 9 Rod ASTM B348 is an alpha-beta titanium alloy composed of titanium, aluminum, and vanadium. It offers excellent corrosion resistance, high strength-to-weight ratio, and superior weldability. This alloy is stronger than commercially pure titanium and is widely used in aerospace, medical, chemical, marine, and automotive applications.

Grade 9 titanium rods can be machined using appropriate coolant and high-speed tungsten carbide or cobalt-based tools. They can also be hot or cold formed using hydraulic presses, power brakes, stretch forming, or drop hammer techniques.

Specifications

Material: Titanium Alloy

Grade: Gr9 / Ti 3Al-2.5V

Standard: ASTM B348

Diameter: 3–600 mm (customizable)

Length: 100–6000 mm

Surface Finish: Polished (custom finishes available)

Physical Properties

Grade Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
Gr1 240 170 24
Gr2 345 275 20
Gr4 550 483 15
Gr5 895 828 10
Gr7 400 275 18
Gr9 620 483 15
Gr12 483 348 18
Gr23 793 759 10

Chemical Composition (Gr9)

Element Max (wt %)
Fe 0.25
O 0.15
N 0.03
C 0.08
H 0.015
Al 2.5–3.5
V 2.0–3.0
Ti Balance

Applications

  1. Aerospace & Defense: High-performance aircraft components, military defense systems.

  2. Medical: Surgical implants, orthopedic devices, and prosthetics.

  3. Chemical Processing: Equipment requiring corrosion resistance and strength.

  4. Marine: Propellers, fasteners, and structural components in seawater environments.

  5. Automotive: Engine components, structural parts, and high-performance vehicles.

Advantages

Excellent strength-to-weight ratio

High corrosion resistance

Good weldability and formability

Biocompatible for medical applications

Easy to machine and fabricate

Can be customized in size, length, and finish
