Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Titanium Plate Heat Exchanger Aerospace Medical Pressure Vessels
Specifications
Brand Name :
Changsheng
Model Number :
AMS 4911
Certification :
ISO 9001;2015
Place of Origin :
China
MOQ :
10kg
Price :
$15.00 - $30.00/ kg
Payment Terms :
L/C, T/T, Western Union, MoneyGram,paypal
Supply Ability :
2000kgs/month
Delivery Time :
15-30days
Packaging Details :
Stardard export package
Surface Quality :
Smooth, Clean, No Cracks, No Scratches
Size :
T.0.8-20MM*W.1000*L
Application :
Aerospace, Chemical Industry, Medical, Marine, Automotive
Feature :
High Elongation Rate
Technique :
Hot Rolled
Other Grade :
GR1 GR2 GR3 GR4
Standard :
ASTM B265, AMS 4911, AMS 4919, AMS 4902
Key Word :
Ti 6Al4V Alloy Plate supplier
Sizes :
0.3mm to 100mm
Mateiral :
Titanium GR5 6AL 4V
Processing :
CNC, forge, rolling and welded
Tolerance :
+/-0.1mm, Width +/-1mm, Length +/-2mm
Wall Thickness :
0.3-20mm
Production Standards :
ASTM B265, ASME SB265, ISO 9001
Applications :
Aviation and aerospace industry
Description

Introduction

Titanium plate implementation standards include both national and international specifications.

Chinese standards: GB/T 3621-2007, GB/T 13810-2007

American standards: ASTM B265, ASTM F136, ASTM F67, AMS 4928

Among these, AMS 4911 specifically covers Ti-6Al-4V (Grade 5) titanium alloy in sheet, strip, and plate forms for aerospace and high-performance engineering applications.

Specification

Product Form Size Range (Thickness)
Titanium Coil 0.12" – 0.125"
Titanium Sheet 0.12" – 0.125"
Titanium Plate 0.125" – 4.00"

Common Sheet/Plate Sizes
Thickness: from 0.012"
Width: < 59"
Length: < 118"

Typical stocked dimensions:

0.032" × 36" × 96"

0.040" × 36" × 96"

0.063" × 36" × 96"

0.071" × 36" × 96"

0.080" × 36" × 96"

0.090" × 36" × 96"

Mechanical Properties

Property Requirement
Tensile Strength ≥ 900 MPa
Yield Strength (0.2% Offset) ≥ 825 MPa
Elongation (A50mm) ≥ 10%
Hardness ≤ 36 HRC

Chemical Composition

Element Min (%) Max (%)
Aluminum (Al) 5.50 6.75
Vanadium (V) 3.50 4.50
Iron (Fe) — 0.30
Oxygen (O) — 0.20
Carbon (C) — 0.08
Nitrogen (N) — 0.05 (500 ppm)
Hydrogen (H) — 0.015 (150 ppm)
Yttrium (Y) — 0.005 (50 ppm)
Other Elements, each — 0.10
Other Elements, total — 0.40
Titanium (Ti) Remainder

Applications

  1. Aerospace Industry
    Used in engine components, structural frames, and airframe panels. Ti-6Al-4V combines high strength, light weight, and superior resistance to heat and corrosion, improving aircraft performance and lifespan.

  2. Medical and Healthcare
    Due to its excellent biocompatibility and mechanical strength, this alloy is widely used in surgical implants, dental prostheses, and orthopedic devices.

  3. Marine Engineering
    Titanium’s excellent resistance to seawater corrosion makes it ideal for subsea equipment, pipelines, and deep-sea exploration systems.

  4. Automotive Manufacturing
    Increasingly used in high-performance and luxury vehicles for engine components and structural parts, reducing weight while maintaining strength and safety.
