GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
GB/T3625 And ASTM B338 Standard Titanium Welded Pipe Gr1 Gr2 Gr5
Specifications
Brand Name :
FHH
Place of Origin :
Xi'an,China
MOQ :
200kgs
Payment Terms :
L/C, D/P, T/T
Supply Ability :
as your request
Delivery Time :
5--10days
Packaging Details :
All goods are packed in wooded case
Commodity :
Titanium welded pipe
Materials :
Titanium metal or Alloy
Grade :
Gr1,Gr2,Gr5 etc.
Standard :
Nonstandard or ,ASTM F67,AMS4928,ASTM F136,ASTM B348，BT1-0,TP270,TP550,TP450 etc.
Technical :
welded
Dimension :
customized or standardisation
Description

The company has the first large diameter titanium tube continuous production line in Asia, 1120 machines, and 30 machines /40 machines /45 machines /60 machines /90 machines and other continuous pipeline 7, using plasma + argon arc welding (P+T) straight seam welding technology, can process and produce the wall thickness of 0.35mm-10mm, diameter of 8mm-426mm titanium tubes; And has universal testing machine, ultrasonic inspection, eddy current inspection, underwater airtight and other testing equipment.

The company produces titanium welded pipes in strict accordance with the Chinese national standard GB/T3625 and the American standard ASTM B338. The product specifications include (diameter 8mm-1016mm, wall thickness 0.35mm-60mm), of which φ8mm-φ426mm can be produced online. Titanium welded pipes Φ80-φ159 and other specifications are widely used in automobile exhaust pipes, and the products are exported to Southeast Asia, the United States and Europe and other international markets; φ8-φ45 small-diameter welded pipes are widely used in refrigeration and heating industries such as condensers and heat exchangers. Other specifications titanium and nickel-based alloy welded pipe is widely used in aerospace, petrochemical, power engineering, seawater desalination, environmental protection equipment, daily necessities and other fields.

Item Standard Material Size(mm)

Heat exchanger

And Condenser tube

ASTMB338,ASTMB337,

ASTMB861

 Grade1,2,3 OD(5-114)X(0.3—10)XL1200mmMax
Corrosion Resistant Tubes ASTMB338 Grade7,Grade12 OD(5-114)X(0.5—4.5)Xlength 12000mmMax
BikeFrame/Wheelchair/Exhaust tube/Pipes

ASTMB338

 Gr9/Ti3Al2v5 OD(38.1—44.5)X(0.9-3.15)X(L1000—2000MM)
Automobile&MotorCycle Exhaust Tube/Pipes ASTMB337/338 Gr1,Gr2,Gr9 OD(38.1—88.9)X1.2X(L1000—2000mm)
Marine Industry ASTM/AMS Gr2,Gr5,Gr7,Gr12 OD(23.1-210)X(W0.5-6.0)X(L1000-6000mm)

Any oreder,Please state your request in details,Such as :Quantity,Dimension(Length,High,thickness,wideth,or fixed length),Materials,Standard etc.
