BA 2B HL Stainless Steel 316 316L Sheet Plate 0.30 Mm Cold Rolled
BA 2B HL Stainless Steel 316 316L Sheet Plate 0.30 Mm Cold Rolled
BA 2B HL Stainless Steel 316 316L Sheet Plate 0.30 Mm Cold Rolled
BA 2B HL Stainless Steel 316 316L Sheet Plate 0.30 Mm Cold Rolled
BA 2B HL Stainless Steel 316 316L Sheet Plate 0.30 Mm Cold Rolled
BA 2B HL Stainless Steel 316 316L Sheet Plate 0.30 Mm Cold Rolled
Specifications
Brand Name :
Stainless Steel
Model Number :
300 Series,400 Series
Certification :
ISO, AISI, ASTM, GB, EN, DIN, JIS
Place of Origin :
China
MOQ :
1 Ton
Price :
Contact Us
Payment Terms :
T/T L/C and Western Union etc.
Supply Ability :
10000 Ton/Tons per Month
Delivery Time :
Within 7-10 Working Days
Packaging Details :
Waterproof Paper, Steel Strip Packed and other Standard Export Seaworthy Package, or customized package
Name :
Brushed Stainless Steel Sheet Plat
Standard :
JIS, AiSi, ASTM, GB, DIN, EN, JIS, AISI, ASTM, GB, DIN, EN, etc.
Technique :
Hot Rolled , Cold Rolled , Extrusion
Grade :
300 Series,400 Series,200 Series,201/202/304 /304L/316/316L321/310s/410/420/430/440/439ect
Surface finish :
2B/NO.1/BA/Mirror/HL/NO.4/Embossed/Etched etc.
Surface :
BA,2B,HL,2D
Description

316 metal has a greater corrosion resistance than 302 and 304 types. It shows excellent capacity pitting and high temperatures strength over 304. In annealed condition, grade 316 is low magnetic. The 316L stainless steel is an extra low and also carbon modification of Type. Low sensitization properties. Applications of type 316 typically require welding. 316/316L is the most popular austenitic metal utilized in the chemical type industry. In high temperature service, the addition of molybdenum improves the corrosion resistance and bolsters chloride pitting resistance. The technical properties of 316/316L are achieved through handled addition of nitrogen while maintaining a low and also carbon content. Alloy 316/316L is ultimately fitted to applications requiring corrosion and resistance to rust better than Type 304 and it has good elevated temperatures strength.

Product Specification and Size :

Product Specification and Steel Grade (For Reference)

ASTM JIS AISI EN Mill's Standard
Grade S30100
S30400
S30403
S31008
S31603
S32100
S41008
S43000
S43932
S44400
S44500		 SUS301
SUS304
SUS304L
SUS310S
-
SUS321
SUS410S
SUS430
-
SUS444
SUS430J1L		 301
304
304L
310S
316L
321
410S
430
-
444
-		 1.4310
1.4301
1.4307
1.4845
1.4404
1.4541
-
1.4016
1.4510
1.4521
-		 201
202
204Cu3

Tolerance of Width

Tolerance of Width
W < 100 mm 100 mm ≦ W < 1000 mm 1000 mm ≦ W < 1600 mm
± 0.10 mm ± 0.25 mm ± 0.30 mm

Chemical Composition & Mechanical Property

Chemical Composition (For Reference)

ASTM Specification

Steel Grade Ni% Max. Cr% Max. C% Max. Si% Max. Mn% Max. P% Max. S% Max. Mo% Max. Ti% Max. Other
S30100 6.0~8.0 16.0~18.0 0.15 1 2 0.045 0.03 - - N: 0.1 Max.
S30400 8.0~10.5 17.5~19.5 0.07 0.75 2 0.045 0.03 - - N: 0.1 Max.
S30403 8.0~12.0 17.5~19.5 0.03 0.75 2 0.045 0.03 - - N: 0.1 Max.
S31008 19.0~22.0 24.0~26.0 0.08 1.5 2 0.045 0.03 - - -
S31603 10.0~14.0 16.0~18.0 0.03 0.75 2 0.045 0.03 2.0~3.0 - N: 0.1 Max.
S32100 9.0~12.0 17.0~19.0 0.08 0.75 2 0.045 0.03 - 5(C+N)~0.70 N: 0.1 Max.
S41000 0.75 11.5~13.5 0.08~0.15 1 1 0.04 0.03 - - -
S43000 0.75 16.0~18.0 0.12 1 1 0.04 0.03 - - -
S43932 0.5 17.0~19.0 0.03 1 1 0.04 0.03 - - N: 0.03 Max.
Al: 0.15 Max.
Nb+Ti = [ 0.20 + 4 ( C + N ) ] ~ 0.75

Mechanical Property (For Reference)

ASTM Specification

Steel Grade N/mm 2 MIN.
Tensile Stress		 N/mm 2 MIN.
Proof Stress		 % MIN.
Elongation		 HRB MAX.
Hardness		 HBW MAX.
Hardness		 Bendability:
Bending Angle		 Bendability:
Inside Radius
S30100 515 205 40 95 217 No Require -
S30400 515 205 40 92 201 No Require -
S30403 485 170 40 92 201 No Require -
S31008 515 205 40 95 217 No Require -
S31603 485 170 40 95 217 No Require -
S32100 515 205 40 95 217 No Require -
S41000 450 205 20 96 217 180° -
S43000 450 205 22A 89 183 180° -
