Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Specifications
Place of Origin :
China
Condition :
New
Machine Type :
Band Saw Machine
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Marketing Type :
Ordinary Product
Cutting Capacity (mm) :
800mm (800WX800H)
Blade Speed (m/min) :
18/30/60m/min
Saw Blade Tension Method :
Hydraulic
Warranty of core components :
1 Year
Core Components :
PLC
Showroom Location :
Turkey, Germany, Viet Nam, India, Chile, Colombia
Warranty :
1 Year
Weight (KG) :
3000
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant
Key Selling Points :
Multifunctional
Motor Power (kw) :
7.5
Hydraulic Motor Power (kW) :
7.5
After-sales Service Provided :
Engineers available to service machinery overseas
Name :
Big Sized Semi-automatic Horizontal Metal Band Sawing Machine
Color :
As your requirement
Voltage :
As your requirement
Saw blade hydraulic tension :
customized
Cutting capacity :
800mm (800WX800H)
Blade speed :
18/30/60m/min
Blade size :
67x1.6x8860mm
Motor main :
7.5kw
Motor hydraulic :
2.2kw
Packaging Details :
in wooden case (can be fumigeted)
Port :
China port (As your requirement)
Supply Ability :
500 Set/Sets per Month
Price :
$100,000.00/sets 1-2 sets
MOQ :
1 set
Description
Products Description
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Features:
This series Double Column Band Saws is designed by our company, which is mainly used for cutting various ferrous metal and non-ferrous metal.the structure of machine is reasonable,performance stable and reliable, high precision. They are ideal equipments to process lots of small or medium workpiece.
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Model
Unit
GBS-800
GBS-80130
Cutting capacity
mm
800 (800WX800H)
800 (1300WX800H)
Blade speed
m/min
18/30/60
20-65 Inverter
Blade size
mm
67x1.6x8860
67x1.6x9860
Motor main
kw
7.5 (4P)
11 (4P)
Motor hydraulic
kw
2.2
3.75
Coolant pump
kw
0.075
0.075
Workpiece clamping

Hydraulic vice
Hydraulic vice
Blade tensioning

Hydraulic
Hydraulic
Main drive

Gear drive
Gear drive
Table height
mm
570
570
Size outward (LxWxH)
mm
4130x2150x2500
4730x2150x2500

Standard Accessories:

Blade cleaning brush, Working light, Saw frame height selector gauge, Hydraulic blade tension, One piece of
bi-metal saw blade, One set of tools with tool box, Power roller table 2M long, Laser projector, Inverter, Hydraulic shuttle table
feeding (GBS-80130)

Optional Accessories:

Variable vice pressure, Automatic chip conveyor, Power roller table 2M long, Hydraulic
shuttle table feeding
(GBS-800)
Why Choose Us
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Voltage As Your Requirement accuracy Semi-automatic Metal Band Sawing Machine GBS-800
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
