Specifications
Condition :
New
type :
Pillar Drilling Machine
Max. Drilling Dia. (mm) :
500mm
Range of Spindle Speed(r.p.m) :
100 - 1000 r.p.m
CNC or Not :
CNC
Drilling Speed :
2000
Place of Origin :
China
Brand Name :
Timac
Model Number :
DHK-500/6000
Voltage :
280V/320V
Dimension(L*W*H) :
2300x4500x8000
Power (kW) :
30kw
Weight (KG) :
15000 KG
Warranty :
1 Year
Key Selling Points :
Automatic
Showroom Location :
Egypt, France, Germany, Viet Nam, Saudi Arabia, Indonesia, Pakistan, Morocco, Kazakhstan
Applicable Industries :
Garment Shops, Building Material Shops, Machinery Repair Shops, Food & Beverage Factory, Printing Shops
Marketing Type :
Hot Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Gear, PLC, Pressure vessel
Honing diameter range :
100~500 mm
Maximum depth of honing hole :
6000 mm
Tooling clamps the outer circle :
100 mm~650 mm
Machine center height :
>480 mm
Motor power :
15KW (servo motor)
Spindle speed range :
15-150 r/min stepless
Servo motor power :
0.45KW (servo motor)
Reciprocating speed range :
1-30 m/min
Feed motor power :
3KW (servo motor)
Cooling pump flow :
50 L/min
Price :
$50,000.00/sets 1-1 sets
MOQ :
1 set
Description
Products Description
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Specification
DHK-500x6M
Honing diameter range
Ф100~Ф500 mm
Maximum depth of honing hole
6000 mm
Tooling clamps the outer circle of the workpiece
100 mm~650 mm
Machine center height
>480 mm
Rod grinding box motor power
15KW (servo motor)
Rod grinding box spindle speed range
15-150 r/min stepless
Grinding head servo motor power
0.45KW (servo motor)
Reciprocating speed range
1-30 m/min
Feed motor power
3KW (servo motor)
Cooling pump flow
50 L/min
Cooling box volume
200 L
Cooling pump motor power
0.45KW
Surface Roughness Polishing
Ra0.4~Ra0.2μm
Machine size
16500x1000x1700 mm
Machining accuracy
IT7－IT8
Processing roughness
Ra≤0.4(after polishing≤0.2 )
Roundness
≤0.05(depend on thickness)
List of machine accessoiries
S/N
Name
Quantity
1
Machine bed
1 set
2
Grinding box
1 set
3
Grinding rod bracket
2 sets
4
Carriage feeding system
1 set
5
Cooling filter system
1 set
6
Work clamping device
2 sets
7
Protective chip removal system
1 set
8
Electrical control system
1 set
9
Electric box
1 set
10
Cooling oil tank
1 set
11
Magnetic separator
1 set
12
Paper bag filter
1 set
13
Accessories and wrenches
1 set
Why Choose Us
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Deep Hole Honing Machine with 50 L/min Cooling Pump Flow and 0.45KW Servo Motor Power
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
