Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Specifications
Condition :
New
type :
Column Drilling Machine
Max. Drilling Dia. (mm) :
100 mm
Range of Spindle Speed(r.p.m) :
5 - 1200 r.p.m
CNC or Not :
CNC
Place of Origin :
China
Brand Name :
TIMAC
Model Number :
DBSK-100, DBSK-200, DBSK-360
Voltage :
220V/380V
Power (kW) :
30 kw
Weight (KG) :
4000 KG
Warranty :
1 Year
Key Selling Points :
High Safety Level
Showroom Location :
Egypt, Canada, Turkey, United States, Philippines, Indonesia, India, Thailand, Morocco
Applicable Industries :
Manufacturing Plant, Machinery Repair Shops, Other
Marketing Type :
New Product 2020
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Core Components :
Bearing, Other
Machine type :
CNC Skiving Roller Burnishing Machine
CNC or Normal :
CNC
Boring dia. range :
35-100 mm
Processing depth range :
1-12 m
Machine guideway width :
500 mm
Spindle center height :
300 mm
Main motor power :
30 kw
Feed speed range :
5-3000 mm/min(stepless)
Air pressure :
≥0.4 MPa
Numerical control system :
SIEMENS 808
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$200,000.00/sets 1-2 sets
MOQ :
1 set
Description
Products Description
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Specification
Unit
DBSK-100
DBSK-200/250
DBSK-360
Boring dia. range
mm
Φ35-Φ100
Φ40-Φ200/250
Φ60-Φ360
Processing depth range
m
1-12
1-12
1-12
Machine guideway width
mm
500
650
650
Spindle center height
mm
300
350
450
The spindle speed range, grades
r/min
5-1200(stepless)
12-1000(Four stepless)
60-1000
(four shifts, stepless)
Main motor power
kw
30
30/60
(variable frequency)
60/75
(variable frequency)
Feed speed range
mm/min
5-3000 (stepless)
5-3000 (stepless)
5-3000 (stepless)
Feed carriage rapid moving speed
m/min
3-6
3-6
3-6
Workpiece clamping diameter range
mm
Φ40-Φ150
Φ40-Φ300/Φ350
Φ120-Φ450
The feed motor
N.m
27
36
48
Cooling pump motor
kw
5.5 (two group)
5.5 (three group)
5.5 (three group)
The hydraulic pump motor
kw

1.5kw, 1440r/min
1.5kw, 1440r/min
Cooling system rated pressure
MPa
2.5
2.5
2.5
The cooling system flow
L/min
200, 200
(two group)
100, 200, 200
(three group)
200, 200, 200
(three group)
Air pressure
MPa
≥0.4
≥0.4
≥0.4
Numerical control system
-
SIEMENS 808
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Why Choose Us
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Customized CNC Skiving Roller Burnishing Machine For Pipe Boring Dia. Range 35-100 mm
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.

Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )

Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.

Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
