Main Technical Parameters

Progressive Profile Forming

The machine uses 18 roller stations to carry out the forming process in successive stages. Instead of shaping the roofing material in a single operation, the sheet passes through the roller section progressively to develop the required profile.

The number of forming stations is therefore one of the key specifications to check when matching a roll forming machine with a particular color steel tile design.

Roller and Shaft Specifications

The forming components use 45# steel for both rollers and shafts. The specified material treatment includes quenching and plating.

A Φ70 mm shaft diameter is provided for the forming system. These details give buyers specific mechanical parameters to consider when reviewing the construction and configuration of the equipment.

Production Speed

The machine has a specified forming speed of 15–20 m/min.

For production planning, this figure can be used as a reference for the machine's forming speed. The actual operating result should be evaluated in relation to the roofing profile, raw material, and other production conditions.

Cutting and Transmission

The machine combines a CR12 cutter with a chain drive transmission system.

The cutter material and drive method are separate elements of the equipment configuration. When comparing different color steel tile roll forming machines, these specifications can be reviewed together with the roller station count and shaft dimensions.

Power Requirements

The machine is specified with 4+4 kW total power and a 380 V / 50 Hz / 3-Phase electrical configuration.

The power supply should be checked against the electrical conditions at the intended installation location before the machine is put into operation.

Suitable Production Applications

This equipment is intended for color steel tile and metal roofing profile forming. Its continuous roll forming configuration can be used in roofing material production where the required profile corresponds with the machine's forming setup.

Common application categories include:

• Color steel roofing tile production
• Metal roofing profile manufacturing
• Steel roofing material processing
• Continuous roofing profile forming
• Building roof panel production

What Buyers Should Check Before Ordering

When selecting an 18-Station Color Steel Tile Roll Forming Machine, buyers should first confirm the required finished profile and then review the machine's technical configuration.

Key points include the 18-station forming section, 45# steel roller and shaft material, Φ70 mm shaft diameter, CR12 cutter, chain drive, 15–20 m/min forming speed, 4+4 kW power, and 380 V / 50 Hz / 3-Phase electrical supply.

Confirming these specifications in advance helps ensure that the selected equipment corresponds to the intended roofing profile and production setup.
