High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
High-quality Steel Plate Forming Wheel / Trapezoidal Ibr Roof Panel Forming And Rolling Machine
Specifications
Motor Power :
4+4KW
Machine Type :
Roll Forming Machine
Production Capacity :
15-20m/min
Model Number :
23-167-1000-1200
MOQ :
1
Certification :
CE
Machine Frame :
350 H Beam
Payment Terms :
L/C,T/T
Roller Material :
45# Steel
Supply Ability :
60 Sets Per Month
Delivery Time :
30days
Packaging Details :
40GP Container
Decoiler Type :
Hydraulic/manual Decoiler
Cutting Method :
Hydraulic Cutting
Place of Origin :
China
Brand Name :
HC
Panel Thickness :
0.3-0.6mm
Description

Main Technical Parameters

Roller Stations

13Stations

Roller & Shaft Material

45# Steel Quenching and Plating

Diameter of Shaft

Φ70mm

Cutter Material

CR12

Speed

15-20m/min

Total Power

4+4KW

Voltage

380V 50Hz3Phases
