Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Automatic roofing sheet forming machine applicable to the construction market
Specifications
Motor Power :
4+4KW
Delivery Time :
30days
Decoiler Type :
Hydraulic/manual Decoiler
Machine Type :
Roll Forming Machine
Roller Material :
45# Steel
Production Capacity :
15-20m/min
MOQ :
1
Certification :
CE
Cutting Method :
Hydraulic Cutting
Model Number :
20-416
Payment Terms :
L/C,T/T
Machine Frame :
350 H Beam
Place of Origin :
China
Supply Ability :
60 Sets Per Month
Panel Thickness :
0.3-0.6mm
Brand Name :
HC
Packaging Details :
40GP Container
Description

Automatic roofing sheet forming machine applicable to the construction market

Production Introduction

High-Yield Metal Roofing Sheet & Facade Panel Manufacturing Line Built for high-volume structural metal component production, the HC Series Roll Former converts raw galvanized, PPGI, and aluminum coils into rigid architectural roof sheets and wall cladding. Engineered with an ultra-stable 350 H-beam chassis, Φ70mm solid steel shafts, and 16 precision profile-forming stations, this system supports continuous production at speed rates up to 20 m/min. Certified to CE engineering safety standards, it delivers maximum dimensional stability and long system lifespan for global structural steel fabricators.

Technical Specifications


Technical Feature Engineering Detail
Machinery Model HC Construction Grade (Model 20-416)
Output Speed Up to 20 meters per minute
Roller Configuration 16 Stations (45# Quenched Steel, Hard Chrome Finish)
Shaft Specification Φ70mm Solid Shafts
Blade & Mold Material Cr12 Die-Steel Tooling
Transmission System Heavy Duty Chain Drive
Drive Power 4KW + 4KW Dual-Motor Unit
Power Requirements 380V / 50Hz / 3-Phase
Structural Frame Heavy Duty 350 H-Beam Welded Chassis

Target Applications

  • Prefabricated Building Systems :

    • Modular field offices, temporary workforce housing, and residential roof extensions.

  • Industrial Facilities :

    • Commercial logistics warehouses, steel-frame manufacturing plants, and agricultural storage sheds.

Frequently Asked Questions (FAQ )

Q1: What coil thickness does this equipment support for panel production?

A:The system efficiently formats steel and aluminum sheet coils between 0.3mm and 0.6mm thickness.

Q2: How does the system handle length measurement and shearing automatically?

A:An integrated PLC controller tracks panel length via encoder, stopping automatically for hydraulic shearing once targets are met.
