PLC control 16 Roller Shutter Door / door frame roll forming machine
PLC control 16 Roller Shutter Door / door frame roll forming machine
Specifications
Brand Name :
HC
Model Number :
HC85
Certification :
ISO/CE
Place of Origin :
Botou Hebei China
MOQ :
1set
Price :
5000-19000USD
Payment Terms :
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Supply Ability :
20 sets/month
Delivery Time :
30days
Packaging Details :
Main machine is nude,the computer control box is packed by carton box
type :
automatic
control system :
PLC control
cutting method :
fly saw cutting
speed :
8-10m/min
Description

shutter door cold forming machine

a. Main technical parameter:

Suitable plate 0.4-1.5mm Alum or steel
Working speed 10-12m/min
Stations 16sets of rollers
Material of roller 45# advanced steel, plated hard chrome
Material of shaft 45# advanced steel(Diameter: Ø40)
Driven Gear box
Main power 7.5kw
Cutting pneumatic following cutting
Material of cutting knife Cr12,Quench HRC 58-62
Hydraulic Cutting blade 3kw
controlled PLC

Roller Material High grade No.45 forged steel, coated with hard chrome.
Active Shaft Material High grade No.45 carbon wrought steel,
Electric Elements PLC control panel, transducer imported from Mitsubishi of Japan.
Cutter blades Cr12 mould steel with quenched treatment.
other elements from famous supplier in china

Roller Material High grade No.45 forged steel, coated with hard chrome.
Active Shaft Material

High grade No.45 carbon wrought steel,

which can improve the integrated mechanic feature of the shaft.
Electric Elements

PLC control panel, transducer imported from Mitsubishi of Japan.

Other elements are from famous suppliers of China.
Cutter blades Cr12 mould steel with quenched treatment.

Terms

Payment type: 30% T/T prepaid and balance should be paid before loading
Delivery time: 30days after receving advance payment.
Guarantee period: 18months free service/ pay service all the machine life
Installation and training:
If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
Without visiting,we will send you user manual and video to teach you to install and operate.
