5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing
5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing
Specifications
Brand Name :
HC
Model Number :
HC28-200-1000
Certification :
CE
Place of Origin :
China
MOQ :
1set
Payment Terms :
L/C,T/T
Supply Ability :
20 sets/month
Delivery Time :
25-30 days
Packaging Details :
Main roll forming machine and decoiler is nude packing, PLC control system and motor pump are packed with water proof paper, spare parts in carton box. One set of machine needs a 40GP container.
Material Type :
PPGI/GI
Material Thickness :
0.3-0.6mm
Material Width :
1220mm
Roller Stations :
12Stations
Roller & Shaft Material :
45# Steel Quenching and Plating
Diameter of Shaft :
Φ70mm
Cutter Material :
CR12
Drive Type :
Chain Drive
Speed :
4m/min
Total Power :
5.5+5.5KW
Voltage :
380V 50Hz 3Phases(can be customized)
Description
5.5kW Glazed Tile Forming Machine - High Speed Roof Tile Manufacturing Machine

5.5 kW Servo Motor Glazed Tile Roll Forming Machine with high speed operation of 4 m/min

Main Technical Parameters
Parameter Specification
Material Type PPGI/GI
Thickness 0.3-0.6mm
Width 1220mm
Roller Stations 12 Stations
Roller & Shaft Material 45# Steel Quenching and Plating
Diameter of Shaft Φ70mm
Cutter Material CR12
Drive Type Chain Drive
Speed 4m/min
Total Power 5.5+5.5KW
Voltage 380V 50Hz 3Phases (can be customized)
Component & Technical Parameters
Component Description
5T Manual Decoiler 5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing

Supports coil and enables rotary movement. Bearing capacity: 5T. Inner diameter: 470-530mm (adjustable). Equipped with brake device to prevent machine damage from impact during operation.
Feeding Table & Pre-Cutter 5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing

Guides coil into correct position for roll forming. Includes hand pull cutting device for pre-cutting when changing color or thickness.
Shaft & Roller 5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing

Material: 45# Steel Quenching and Plating. Processed rollers are smooth, hard, rust-resistant, and will not scratch sheets during operation.
Hydraulic Pump Station 5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing

Drives cutter for cutting operations. Uses 46# hydraulic oil. Equipped with cooling fan for internal circulation cooling to prevent high oil temperature issues. Solenoid valve brand: Huade.
Touch Screen Control Cabinet 5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing

Features automatic and manual modes. Allows setting of unit length and quantity on touchscreen. Simple and easy to operate system. Electrical components: VFD (Delta), Circuit breaker (Delixi), Contactor (Delixi), Relay (Xinling), PLC (Delta), Transformer (Delixi).
Pressing Section & Cutter 5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing

Blade and pressing mould material: CR12. Features high strength, excellent hardenability, and superior wear resistance.
Output Table 5.5kw High Speed Glazed Tile Roll Forming Machine with 12 Stations for Roof Tile Manufacturing

Collects formed products. Equipped with rollers to facilitate product forwarding without scratching.
Spare Parts Included
Part Quantity
Chains 2 Sets
Solenoid Valve 1 Set
Travel Switch 2 Sets
Open-End Wrenches 2 Sets
Hexagon Wrench 2 Sets
Counter 1 Set
Wrench 2 Sets
Oil Seals 1 Set
Installation Guidelines

Important: The mold used in the tile press equipment requires one upper mold and six lower molds of the same size.

Mold Installation Procedure:

  • Install upper and lower molds first - lower mold mounts directly on hexagonal wheel worktable
  • Upper mold installs on bottom surface of slide with appropriate thickness plate
  • Ensure even gap around all four sides when upper and lower molds are closed
  • Distance between upper and lower mold should equal required blank thickness
  • Use above model as reference for workbench indexing
  • Install remaining five lower molds
  • Begin pressing operation after all molds are installed

Pre-Operation Checklist:

  • Check all connections for firmness
  • Verify installation bolts and nuts are tightened
  • Fill left and right chassis with lubrication oil
  • Conduct test run and observe for vibration, noise, and oil window performance
  • Ensure all moving parts coordinate properly
  • Install mold only after successful test run

Safety Warning: When installing mold, always cut power and manually move motor belt or large gear to position worktable. Raise carriage to highest point and use support object between table and slide bottom surface to prevent accidents from natural fall of anti-skid seat.
