Specifications
Voltage :
12-480V
Place of Origin :
China
Temperature range :
-200~650℃
Certification :
CE
Style :
PT100, PT1000, PT500, K, J
Usage :
Temperature sensor
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Heating Element :
Nichrome Resistance
Delivery Time :
7~10 working days
Pairs quantity of element :
Simplex/duplex
Supply Ability :
100000 pcs per Month
Probe length :
30-1000mm
Types of terminal box :
Anti-spray/water-proof
Packaging Details :
cartons， pallet
Probe material :
Stainless Steel or Nickel
MOQ :
50pcs
Power Source :
Electric
Brand Name :
GME
Temperature :
0-800C
Description

High quality platinum bare thermocouple wire type S, R with noble metal

Description:

Type S, Pt10%Rh-Pt thermocouple is a thermocouple junction often used for extreme high temperatures. Type S, Pt10%Rh-Pt shares a lot of characteristics with type R, Pt13%Rh-Pt thermocouple, but type R has a higher Seebeck coefficient than type S. Temperature range of type S, Pt10%Rh-Pt thermocouple wire is 0°C to +1600°C.

The thermocouple type S is designed for continuous use in oxidizing or inert atmospheres at temperatures up to 1600°C and can withstand brief periods up to 1700°C. Prolonged exposure to high temperatures can cause degradation of the thermocouple, including the possibility of rhodium diffusion into the pure platinum conductor, which results in a reduction in output. Therefore, it’s important to be aware of potential embrittlement caused by the environment.

Code
+Positive leg
-Negative leg
N
Ni-Cr-Si(NP)
Ni-Si-Mg(NN)
K
Ni-Cr-Si(KP)
Ni-Al(KN)
E
Ni-Cr(EP)
Cu-Ni<constantan>(EN)
J
Iron(JP)
Cu-Ni<constantan>(JN)
T
Copper(TP)
Cu-Ni<constantan>(TN)
B
Platinum Rhodium-30%
Platinum Rhodium-6%
R
Platinum Rhodium-13%
Platinum
S
Platinum Rhodium-10%
Platinum

Features

Please note that these ranges are given as indicative values and vary per diameter.

  • In oxidizing or inert atmospheres: Up to 1450°C (2642°F)
  • For long-term continuous use: Up to 1600°C (2912°F)
  • Up to 1700°C (3092°F) for short durations.

Chemical composition

  • SP ( + ) = 90%Pt 10%Rh
  • SN (-) = 100%Pt
