Electric Spring Hot Runner Coil Heater With Thermocouple
Electric Spring Hot Runner Coil Heater With Thermocouple
Electric Spring Hot Runner Coil Heater With Thermocouple
Electric Spring Hot Runner Coil Heater With Thermocouple
Electric Spring Hot Runner Coil Heater With Thermocouple
Electric Spring Hot Runner Coil Heater With Thermocouple
Specifications
Brand Name :
GME
Certification :
CE
Place of Origin :
China
MOQ :
50pcs
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
100000 pcs per Month
Delivery Time :
7~10 working days
Packaging Details :
cartons， pallet
Power Source :
Electric
Dimension :
Customized
Voltage :
12-480V
Sheath material :
Stainless Steel or Nickel
Cross Section :
3.2*1.8mm
Style :
straight or coil
Lead wire :
copper, , fiberglass silicon
Coiling Scheme :
Tangential, radial exits, axial
Description

Electric spring hot runner coil heater with thermocouple

Description:

1) Hot runner heater is the important component of hot runner system, which is made of special technque and high quality material, ensuring its efficient work in the close space, even when the heating jacket temperature is 700 degrees Celsius. Complying with the metric system and the international standard, all models are on the basis of our quality inspection requirements, so as to meet most factories and hot runner machines.

2) we provide several kinds of heaters, such as pipe heater, press in brass heater, coil heater and so on.


Specification:

When you order ,pls provide this information

1. D: Inner Diameter (mm)
2. C: Height(mm)
3. Section Area: E*F(mm)
4. A: Lead Wire
5. Q:Quantity

Sheath Material Cr Ni-Steel
Insulation Material MgO
Resistance Wire Ni Cr 80-20
Maximum Sheath Temperature 700°C
Die Electrical Strength 800V A/C
Insulation > 5 M W
Thermocouple J type (Standard) or K type
Length Tolerance (Straight) 5%
Wattage Tolerance + 10% (+ 5% Available Upon Request)
Resistance Tolerance + 10% (+ 5% Available Upon Request)
Unheated Length 35mm (Standard)
Dimensional Tolerance Coil I.D + 0.1 to 0.2mm

Coil Length + 1mm


Electric Spring Hot Runner Coil Heater With Thermocouple

Application:

1. Injection moulding machine nozzle

2. Hot Runner Nozzles & Bushings.

3. Packaging machineries

4. Hot runner Injection moulds.

5. Injection & Blow Moulding Machine Nozzles.

6. PET prefrom & Thin wall container Moulds

7. Hot runner Manifolds.
