Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Hot Runner Electric Heating Element With Thermocouple
Specifications
Brand Name :
GME
Certification :
CE
Place of Origin :
China
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
100000 pcs per Month
Delivery Time :
7~10 working days
Packaging Details :
cartons， pallet
Power Source :
Electric
Dimension :
Customized
Voltage :
120v 220v 240v 380v, 220V
Sheath material :
Stainless Steel or Nickel
Cross Section :
3.0x3.0,3.3x3.3mm,4.50 * 4.50 mm
Style :
straight or coil
Lead wire :
, fiberglass , metal mesh
Coiling Scheme :
Tangential, radial exits, axial
Material :
Brass and stainless steel
Application :
manifolds, hot runner/ injection
Surface finishing :
bright or soft annealed
Insulation Resistance :
> 5 MΩ
Description

Hot runner electric heating element coiled heaters with thermocouple

Description:

1. Hot runner coil heaters are made of nickel chrome resistance wire placed inside chrome nickel steel tube filled with MgO powder and compacted for faster and efficient heat transfer.

2. The heaters are annealed to acquire malleability for bending into any shape. Hot runner heaters with built in thermocouple are also available. Hot runner bushes are produced with hot runner heaters of different cross section with inner brass and outer stainless steel cover.


Specification:

Features of Hot Runner Coil Heater :

1.Standard sizes available with various cross section
2.Various Watt Density option available
3.Designed for even heat profile
4.Precision fit on Hot Runner Nozzles
5.Highly Non-corrosive

Product Name Hot Runner Coil and Cable Heaters with thermocouple K/J
Section area

2.3*4.3,2.7*4.5,3.0*3.0,3.5*3.5,2.2*4.2,2.7*4.5,3.5*3.5
Sheath Material Stainless Steel
Insulation Material High Pure MgO
Heating Coil ID 10mm-38mm
Voltage 110-240V / 50-60Hz
Wattage 70w-3000w
Build-in thermocouple With Thermocouple J/K
Available sheath nylon,metal braided,fiberglass ,silicone rubber, kevlar
Sheath's color standard is black,other color is also available
Resistance Wire Ni Cr 80-20
Maximum Sheath Temperature 700°C
Length Tolerance (Straight)

5%

Hot Runner Electric Heating Element With Thermocouple

Application:

1.Caustic Cyanide used in gold processing


2.Caustic solutions Detergent


3.Sterilizing equipment


4.Plastic processing&packaging machinery


5.Ovens&dryers

6.Dies&Tools


7.Water& Oil heating appliances


8.Vending machines


9.Medical equipment information about what you need.
