PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse
Specifications
Brand Name :
CNAMPFORT
Model Number :
SL-1537
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
1000PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100,000,000pcs per month
Delivery Time :
1-2 Weeks
Packaging Details :
Bulk
Name :
PCB Fuse Holder
Current Rating :
15A
Voltage Rating :
125V
Fuse Type :
MINI
Flammability Rating :
94-V0
Mounting Method :
Horizontal Mount
Replace P/N :
01530007Z
P/N :
SL-1537
Description

PCB Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse

01530007Z EQUIVALENT ACS FUSEHLDR HORIZONTAL MT | Series: MINI - 153-PC

The MINI 153-PC Series 32V PCB Fuse Holder lets you easily mount a MINI blade-style fuse on a printed circuit board. It's designed with a circuit board locking anchor to ensure secure attachment to the PCB, and it has standoffs, which accommodate circuit board washing. The heat-resistant thermoplastic body carries a UL 94 V-0 flammability rating, making the fuse holder ideal for automotive PCB applications, such as protecting circuits for vehicle control systems, navigation and entertainment systems, and automotive sensors. This MINI 153-PC Series PCB fuse holder (01530007Z) features a horizontal mounting style.

Applicable For MINI blade fuse
Electrical Rated for current up to 15A 32VAC
Insulating Base body PA + 30%GP
Contact Brass with Tin plated

Features
- Horizontal mounting style
- Designed to allow installation of reliable and widelyavailable 32V MINI blade-style fuses (sold separately) upto 20 amps on a printed circuit board

- Standoffs accommodate circuit board washing

- Circuit board locking anchor ensures a secure mechanicalbond with the PCB

- Thermoplastic UL 94 V-0 rated body is heat-resistant

- PCB fuse holder clip is made from copper alloy with a tinplated finish for corrosion resistance

- Available in horizontal, stackable vertical, and single vertical(end unit) mounting styles

Applications

- Automotive PCB Fusing

- forautomotive PCB applications, such as protecting circuitsfor vehicle control systems, navigation and entertainmentsystems, and automotive sensors

Specification

Name MINI BLADE FUSE HOLDER
P/N SL-1537/153
RATED VOLTAGE 125V MAX
RATED CURRENT 15A
HOUSING PA

PCB Mount Fuse Holder 1530007 MINI Blade Fuse Holder SL-1537 for 297 Fuse

PART NUMBER DESCRIPTION CURRENT RATING MAX FUSE TYPE MOUNTING METHOD MAX VOLTAGE RATING
01530007Z ACS Fuse Holder Horizontal Mount 20 Amps MINI (297) PC Horizontal Mount 32V
01530008Z ACS Fuse Holder Vertical Mount 20 Amps MINI (297) PC Vertical Mount 32V
01530009Z ACS Fuse Holder Vertical Mount 20 Amps MINI (297) PC Vertical Mount 32V
01530008LXN Fuse Holder B-P.C.-Board Vertical / Packed 50 20 Amps MINI (297) PC Vertical Mount 32V
