PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection
Specifications
Brand Name :
AFTPTC
Model Number :
KTY81-210
Certification :
ROHS
Place of Origin :
CHINA
MOQ :
1000 Pieces
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100,000,000 pieces/month
Delivery Time :
1-2 Weeks
Packaging Details :
Bulk,500/bag ; tape in ammo ,5000 per box
Name :
KTY81-210 Silicon Temperature Sensors
Shape :
Axial
Operating temp :
-50~+150C
R25 :
2000 OHMS
Resistance range :
1980-2020 OHMS
Tolerance :
±1%
Description

PTC Thermistor 2 KOhms KTY81-210 Silicon Temperature Sensors for Automotive Motor Thermal Protection

Description

KTY81/82/84 Series Temperature Sensors. The temperature sensor has been widely used in the field of solar water heater temperature measurement, automobile oil temperature measurement, oil module, diesel injection system, transfer temperature measurement, engine cooling system, climate control system industry is mainly used in overheat protection, heating control system, power supply protection, etc.

Features

Our company is a high-tech enterprise specializing in the production of KTY-81/82/84 series temperature sensors. The production of KTY temperature sensor is carefully made of imported Philips silicon resistance elements. It has the advantages of high precision, good stability, strong reliability, and long product life. It is suitable for small pipelines and small spaces with high-precision temperature measurement. Continuous measurement and control of temperature on the industrial site.

Application

1. Automobile oil temperature measurement, oil module, diesel injection system, transfer temperature measurement, engine cooling system
2. Climate control system industry is mainly used in overheating protection, heating control system, power supply protection, etc.
3. In particular, the temperature measurement linear requirements are relatively high in the field of scientific research and industrial fields more suitable

Specification

No. Parameter Symbol Test Condition Min. Nor. Max. Unit
1 Resistance value at 25°C R25

constant temperature

25±0.05℃

 1980 2000 2020 Ω
3 Dissipation factor δ In still air 1.5 / / mW/℃
4 Thermal time constant τ In still air / / 7 s
5 Insulation resistance / DC=100V 100 / / MΩ
6 Max. Work Current Imax / / / 8 mA
7 Rated Current IN / / 2 / mA
8 Rated Power Pmax / / / 50 mW
9 Operating temperature TA -50 ~ +150℃
10 Storage time Tmin 2 years (room temperature, relative humidity <60%)
