1.2W/M.K Thermal Pads Silicone Cooling Pad Heat Resistance With Self-Adhesive Films For PC Laptop
1.2W/M.K Thermal Pads Silicone Cooling Pad Heat Resistance With Self-Adhesive Films For PC Laptop
1.2W/M.K Thermal Pads Silicone Cooling Pad Heat Resistance With Self-Adhesive Films For PC Laptop
1.2W/M.K Thermal Pads Silicone Cooling Pad Heat Resistance With Self-Adhesive Films For PC Laptop
Specifications
Brand Name :
Ziitek
Model Number :
TIF112-12-10S-K1
Certification :
UL & RoHS
Place of Origin :
China
MOQ :
1000pcs
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
1000000 pcs/month
Delivery Time :
3-5 work days
Packaging Details :
24*13*12cm cartons
Products name :
1.2W/M.K Thermal Pads Silicone Cooling Pad Heat Resistance With Self-Adhesive Films For PC Laptop
Keywords :
Thermal Pad
Thickness range :
0.012"(0.3mm)
Color :
Gay/Light amber
Dielectric Constant :
4.5MHz
Dielectric Breakdown Voltage :
>5500 VAC
Fire rating :
94 V0
Thermal conductivity :
1.2W/m-K
Application :
GPU CPU PC Laptop
Description

1.2W/M.K Thermal Pads Silicone Cooling Pad Heat Resistance With Self-Adhesive Films For PC Laptop

Company Profile

Dongguan Ziitek Electronic Material Technology Co., Ltd. was established in 2006. Is a high-tech enterprise specializing in the research, development, production and sales of thermal interface materials. We mainly produce: heat-conducting joint filler, low melting point thermal interface materials, heat-conducting insulator, heat-conducting adhesive tape, heat-conducting interface pad and heat-conducting grease, heat-conducting plastic, silicone rubber, silicone rubber foam, etc. We adhere to the business philosophy of "survival by quality, development by quality", and continue to provide the most efficient and best service for new and old customers with excellent quality in the spirit of rigor, pragmatism and innovation.

The TIF®112-12-10S-K1 Series is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.

Features


> Good thermal conductive: 1.2W/mK

> Naturally tacky needing no further adhesive coating
> Soft and Compressible for low stress applications
> Available in varies thickness


Applications


> LED TV / LED Lit Lamps
> Automotive engine control units
> SAD-DC Power Adapters
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)

> Micro heat pipe thermal solutions
> Memory Modules

> Routers

> Telecommunication hardware

> Mainboard/mother board

Typical Properties of TIF®112-12-10S-K1 Series
Property Value Test method
Color Gray/Light amber Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Renforcement Carrier Polyimide film ******
Thickness range 0.012"(0.3mm) ASTM D374
Specific Gravity 2.2 g/cc ASTM D792
Hardness 60±5 Shore 00 ASTM 2240
Operating Temp -45 ~ 120℃ ******
Dielectric Breakdown Voltage ≥5500 VAC ASTM D149
Dielectric Constant @1MHz 4.5 MHz ASTM D150
Volume Resistivity ≥1.0X1012 Ohm-cm ASTM D257
Fire rating 94 V0 UL E331100
Thermal conductivity 1.2W/m-K ASTM D5470

Product Thicknesses: 0.012-inch (0.3mm)

Product Sizes: 8" x 16"(203mm x406mm)


Individual die cut shapes and custom thickness can be supplied. Please contact us for confirming
Safe disposal method does not require special protection.The storage condition is low temperature anddry, away from open fire and away from direct sunlight. For detailed method, please refer to the product material safety data sheet.

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

1.2W/M.K Thermal Pads Silicone Cooling Pad Heat Resistance With Self-Adhesive Films For PC Laptop

Advantage

Ziitek has independent R&D team. This team is experience, rigorous and pragmatic.

They undertake the core research and development tasks of Ziitek thermal conductive materials. With well-equipped testing equipment, we Ziitek can also do some tests with customers' samples, so we can find a more suitable Ziitek materials for every customer.
