High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling
High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling
High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling
High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling
Specifications
Brand Name :
Ziitek
Model Number :
TIF500-50-11ES
Certification :
UL & RoHS
Place of Origin :
China
MOQ :
1000pcs
Price :
0.1-10 USD/PCS
Payment Terms :
T/T
Supply Ability :
1000000 pcs/month
Delivery Time :
3-5 work days
Packaging Details :
24*13*12cm cartons
Products name :
High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling
Construction & Compostion: :
Ceramic Filled Silicone Elastomer
Keywords :
Silicone Thermal Cooling Pad
Hardness :
35 Shore 00
Density :
3.3 g/cm³
Thermal conductivity :
5.0W/m-K
Color :
Gray
Thickness Range :
0.25~5.0mm /(0.010~0.20 inch)
Application :
AI Processors Cooling
Description

High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling

Products Description

TIF®500-50-11E Series is an ultra-soft thermal interface material designed specifically to protect precision components that are extremely sensitive to mechanical stress. This product combines high thermal conductivity with exceptional gel-level softness,achieving a perfectly low-stress fit. It is suitable for addressing issues such as large tolerances, uneven surfaces,and the susceptibility of precision components to mechanical damage in high-precision assemblies.


Features:

> High thermal conductivity
> Super soft and highly compliant
> Self-adhesive without the need for additional surface adhesives

> Good insulation performance
> Easy release construction
> Electrically isolating
> High durability


Applications:

> Mass storage devices
> Automotive electronics
> Set top boxes
> Audio and video components
> IT infrastructure
> GPS navigation and other portable devices
> CD-Rom, DVD-Rom cooling
> LED Power Supply
> LED Controller
> LED Ceilinglamp
> Monitoring the Power Box
> AD-DC Power Adapters
> Rainproof LED Power

> Signal communication
> New energy vehicle
> Motherboard chip
> Radiator

Typical Properties of TIF®500-50-11E Series
Property Value Test method
Color Gray Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Density(g/cm³) 3.3 ASTM D792
Thickness Range(inch/mm) 0.010~0.020 0.030~0.200 ASTM D374
(0.25~0.5) (0.75~5.0)
Hardness 65 Shore 00 35 Shore 00 ASTM 2240
Recommended Operating Temperature -40 to 200℃ ******
Breakdown Voltage(V/mm) ≥5500 ASTM D149
Dielectric Constant 9.0 MHz ASTM D150
Volume Resistivity ＞1.0X1012 Ohm-meter ASTM D257
Flame rating V-0 UL 94 (E331100)
Thermal conductivity 5.0 W/m-K ASTM D5470
5.0 W/m-K ISO22007

High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling

Product Specifications

Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"× 16" (406 mm×406 mm)
Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.
High Performance Thermal Pad Soft Silicone Thermal Cooling Pad For AI Processors Cooling

Company Profile

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

UL

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China

Q: Do you accept custom orders ?

A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information .

Q: How much are the pads?

A: Price is depended on your size, thickness, quantity, and other requirements, such as adhesive and others. Please let us know these factors first so that we could give you an exact price.
