High Thermal Conductivity 240W High Temperature Resistance Thermal Graphite Sheet For Smart Phone
High Thermal Conductivity 240W High Temperature Resistance Thermal Graphite Sheet For Smart Phone
High Thermal Conductivity 240W High Temperature Resistance Thermal Graphite Sheet For Smart Phone
High Thermal Conductivity 240W High Temperature Resistance Thermal Graphite Sheet For Smart Phone
Specifications
Brand Name :
Ziitek
Model Number :
TIR610
Certification :
RoHs
Place of Origin :
China
MOQ :
1000PCS
Price :
0.1-10 USD/PCS
Supply Ability :
100000pcs/day
Delivery Time :
2-3 work days
Packaging Details :
1000pcs/bag
Product name :
High Thermal Conductivity 240W High Temperature Resistance Thermal Graphite Sheet For Smart Phone
Color :
Black
Application :
Smart Phone
density :
2.2g/cc
Thermal conductivity (Z Axis Direction) :
6.0W/m-K
Thermal conductivity (X-Y Axis Direction) :
240W/m-K
Hardness :
85 Shore A
Keywords :
Thermal Graphite Sheet
Material :
Natural Graphite
Description

High Thermal Conductivity 240W High Temperature Resistance Thermal Graphite Sheet For Smart Phone

TIR™610 Series products are high-performance and heat-conductive interface materials with the reasonable prices.They can be used in applications where no requirement for electric insulation is specified.The unique grain orientation and plate structure enable these products to adapt to different contact surfaces closely, and thus the maximized heat conduction function is attained.

Feature
> Thermal Conductivity: 240 W/mK

> Easy to assemble
> Ultra-thin type
> RoHS Compliant

Application

> Telecommunication hardware
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)
> CPU
> Display card
vMainboard/mother board
> Notebook
> Power supply
> Heat pipe thermal solutions
> Memory Modules

Typical Properties of TIR™600 series
Product Name TIR™605 TIR™606 TIR™610 TIR™620 Test Method
Colour Black
Material Natural Graphite
Thickness 0.005" (0.127 mm) 0.006" (0.152 mm) 0.010" (0.254 mm) 0.020" (0.508 mm) ASTM D751
Total Thickness +/- 10% +/- 10% +/- 5% +/- 5% ASTM D751
Density 2.2 g/cc 2.2 g/cc 2.2 g/cc 2.2 g/cc ASTM D297
Hardness 85 Shore A ASTM D2240
Operation Temperature -200℃~ 300℃ ******
Volume Resistivity 3.2X10³ Ohm-meter ASTM D257
Typical Thermal Conductivit (In Z axis) 6.0W/m-K 6.0W/m-K 6.0W/m-K 6.0W/m-K ASTM D5470
Typical Thermal Conductivity (In X-Y axis) 240 W/m-K 240 W/m-K 240 W/m-K 240 W/m-K ******
Thermal Resistance @100psi 0.037 (in²℃/W) 0.042 (in²℃/W) 0.057 (in²℃/W) 0.098 (in²℃/W) ASTM D5470

Standard Sheets Sizes :

500mm x 50m

TIR™600 series Individual die cut shapes can be supplied.

Consult the factory alternate thickness.

High Thermal Conductivity 240W High Temperature Resistance Thermal Graphite Sheet For Smart Phone

Packaging Details & Lead time

The packaging of Natural graphite sheet

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Company profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: What's the thermal conductivity test method given on the data sheet ?

A: All the data in the sheet are actual tested.Hot Disk and ASTM D5470 are utilized to test the thermal conductivity.

Q: How to find a right thermal conductivity for my applications

A: It depends on the watts of power source , ability of heat dissipation. Please tell us your detailed applications and the power, so we can recommend most suitable thermal conductive materials.
