Factory Custom Size Battery Led Laptop Termal Pad 2W 1.5mm Silicone Themals Conductive Pads For GPU CPU Cooling
Factory Custom Size Battery Led Laptop Termal Pad 2W 1.5mm Silicone Themals Conductive Pads For GPU CPU Cooling
Factory Custom Size Battery Led Laptop Termal Pad 2W 1.5mm Silicone Themals Conductive Pads For GPU CPU Cooling
Factory Custom Size Battery Led Laptop Termal Pad 2W 1.5mm Silicone Themals Conductive Pads For GPU CPU Cooling
Specifications
Brand Name :
ZIITEK
Model Number :
TIF560-20-11US
Certification :
UL and RoHs
Place of Origin :
China
MOQ :
1000pcs
Price :
Negotiation
Supply Ability :
10000/day
Delivery Time :
3-5work days
Packaging Details :
1000pcs/bag
Payment Terms :
T/T
Products name :
Factory Custom Size Battery Led Laptop Termal Pad 2W 1.5mm Silicone Themals Conductive Pads For GPU CPU Cooling
Thickness :
1.5mmT
Thermal conductivity& Compostion :
2.0W/m-K
Continuos Use Temp :
-40℃ to 200℃
Construction :
Ceramic filled silicone elastomer
Specific Gravity :
2.5 g/cc
Hardness :
20 Shore 00
Color :
Dark Gray
Keywords :
Laptop Termal Pad
Application :
Battery Led Laptop GPU CPU Cooling
Description

Factory Custom Size Battery Led Laptop Termal Pad 2W 1.5mm Silicone Themals Conductive Pads For GPU CPU Cooling

TIF®560-20-11US Series is an ultra-soft thermal interface material designed specifically to protect precision components that are extremely_sensitive to mechanical stress. This product combines high thermal conductivity with an exceptionally gel-like softness, achieving a low-stress perfect fit. It is suitable for addressing issues in high-precision assemblies, such as large tolerances, uneven surfaces, and the susceptibility of delicate components to mechanical damage.

Features:
> Excellent thermal conductivity 2.0W/mK

> Moldability for complex parts
> Soft and compressible for low stress applications
> Easy release construction
> Electrically isolating
> High durability


Applications:

> Cooling components to the chassis of frame
> CPU and GPU processors and other chipsets
> High-performance computing (HPC)

> Industrial equipment
> Network communication devices

> New energy vehicles
> LED CPU GPU MOS

> Automotive electronics
> Set top boxes
> Audio and video components
> IT infrastructure

Typical Properties of TIF®500-20-11US Series
Property Value Test method
Color Dark Gray Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Density(g/cm³) 2.5 ASTM D792
Thickness Range(inch/mm) 0.010~0.020 0.030~0.200 ASTM D374
(0.25~0.50) (0.75~5.0)
Hardness 65 Shore 00 20 Shore 00 ASTM 2240
Recommended Operating Temperature -40 to 200℃ ******
Breakdown Voltage(V/mm) ≥5500 ASTM D149
Dielectric Constant 4.5 MHz ASTM D150
Volume Resistivity ＞1.0X1012 Ohm-meter ASTM D257
Flame rating V-0 UL94 (E331100)
Thermal conductivity 2.0 W/m-K ASTM D5470
2.0 W/m-K ISO22007

Product Specifications
Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"X 16" (406 mm×406 mm)

Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF® series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.
Factory Custom Size Battery Led Laptop Termal Pad 2W 1.5mm Silicone Themals Conductive Pads For GPU CPU Cooling
Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated
