Specifications
Brand Name :
Polywell
Model Number :
PW-HK02B
Certification :
SGS
Place of Origin :
China
MOQ :
5000 meters
Price :
$0.20 - $0.4 / Meter
Payment Terms :
T/T
Supply Ability :
100000 meters per day
Delivery Time :
15-20 working days
Packaging Details :
Linear or Roll
Material :
PA66 GF25
Color :
Black
Application :
Thermal break aluminum
Density :
1.25-1.35 g/cm3
Refractoriness :
230-255°C
Size :
Customized
Length :
6 meters/piece
Product Name :
HK Shape Extruded Nylon Thermal break strips for Aluminun Windows
OEM Service :
Available
Port :
Shanghai
Description
PA66 GF25 Thermal Break Strip Polyamide Extrusion In Windows And Doors

Product Description

Polyamide Thermal Break Strips for Aluminun Windows

Nylon66 Thermal barrier strip of polyamide extruding product, which is widely used for bridge insulating aluminum profile, has excellent performance such as high temperature resistance, chemical resistance, ultraviolet resistance and water resistance. The Linear Expansion Coefficient of the product is close to that of aluminum profile, which makes long durance of spacer and aluminum profile. The product has been tested by the Material Test Center of SGS. The product meets the National Standard of GB/T23615.1-2009.
Shape I, shape C, shape T, shape CT and shape HK is the most common shape, we can also according to customer requirements or drawings to customize other special shape.
PA66 GF25 Thermal Break Strip Polyamide Extrusion In Windows And Doors

Detailed Infomation
PA66 GF25 Thermal Break Strip Polyamide Extrusion In Windows And DoorsPA66 GF25 Thermal Break Strip Polyamide Extrusion In Windows And Doors

Advantages
1. The Heat Insulation Profiles for windows & doors were manufactured in line with Chinese national standards GB/T 23615.1-2009, with extremely high mechanical strength and withstand tensile shear stress, can be acted as the connecter to the hardware.
2. The thermal expansion coefficient is the same as that of the aluminum alloy, which can avoid hesitation thermal expansion and contraction and lead to the separation between the thermal insulation strip and the metal.
3. High corrosion-resistance, weather-resistance, heat-resistance, alkali-resistance and long life of usage.
4. Excellent product tolerance of less than 0.1mm, ensuring air and water tightness and overall composite profile dimensions.
5. The thermal expansion coefficient of PA66GF25 is similar to aluminum thus ensures that product does not affect the integrity of the thermally insulated aluminum profiles.
6. Precisely dimension ensures the lifespan of aluminum extrusion tools, no danger of bending cracks during rolling, very good knurling effect at the hammer head and easy to assemble.
For shape, we can customize it according to customers' requirements.

Application

It is mainly used in insulation broken bridge aluminium products, helping to reduce heat loss or heat gain through the aluminum, and has better performance in terms of power usage.

Product Parameters

Item
Unit
GB/T 23615.1-2009
PW-Technical specification
Density
g/cm3
1.3±0.05
1.28-1.35
Linear expansion coefficient
K-1
(2.3-3.5)×10-5
(2.3-3.5)×10-5
Vicat softening temperature
ºC
≥230ºC
≥233ºC
Melting point
ºC
≥240
≥240
Testing for tensile cracks
-
No cracks
No cracks
Shore hardness
-
80±5
80-85
Impact strength(Unnotched)
KJ/m2
≥35
≥38
Tensile strength(longitudinal)
MPa
≥80a
≥82a
Elasticity modulus
MPa
≥4500
≥4550
Elongation at break
%
≥2.5
≥2.6
Tensile strength(transverse)
MPa
≥70a
≥70a
High temperature tensile strength(transverse)
MPa
≥45a
≥47a
Low temperature tensile strength(transverse)
MPa
≥80a
≥81a
Water resistance tensile strength(transverse)
MPa
≥35a
≥35a
Aging resistance tensile strength(transverse)
MPa
≥50a
≥50a

Our Company

PA66 GF25 Thermal Break Strip Polyamide Extrusion In Windows And Doors

Storage Conditions
The strips will be stored in the ventilated and dry environment, horizontally placed, paying attention to waterproof, keeping away from the heat source, avoiding heavy pressure and the contact with acid, alkali as well as organic solvent.

Delivery
We have the production capacity of 100000 meters per day. For common specifications, we have molds, and will be shipped in 15-20 working days after receiving the deposit.

Welcome to visit our company!

Please feel free to contact us if you have any questions.
Whatsapp: +8613584481777
Skype: Camille_1877
Wechat: Camille_4790

Our Service

Before sales

1. introduce products in detail
2. recommend suitable solutions
3. provide with reference information

During manufacturing

1. provide with layout and engineering conditions
2. inform the processing status
3. offer related documents

After Sales

1. provide installation, commissioning and training
2. offer spare parts
3. Provide with necessary technical support
