Specifications
Place of Origin :
Guangdong, China
Brand Name :
Theodoor
MOQ :
50
Price :
$299
Operating voltage :
230 VAC
Mounting type :
Wall / Window Mount
Airflow :
2000m³/h
Weight :
15 KG
Size options :
900, 1000, 1200, 1500, 1800, 2000mm
Cover material :
Stainless Steel 304
Fan type :
Cross flow fan
Power supply :
220-240/110V 50/60HZ
Control type :
Button+Remote
Motor power :
140-350W
Air volume :
840-3600m³/h
Air speed :
9-13m/s
Noise level :
54-61dB
Continuous operation :
5000 hours
Motor safety :
Overheating protector
Description

Titan Series Stainless Steel Air Curtain For Refrigerator Door

Feature

1. Compact design with stainless steel cover, easy installation and simple maintenance.

2. The optimized fan wheel provides stable & even air flow. It has large air volume and low noise

performance.

3. The reliable designed motor, with overheating protector and has safety operation of 5000 hours

continuously without defect.

4. Adopting remote control or switch, it’s able to adjust high and low air velocity.

5. Two series available in different air velocity: 9-11m/s, 10-13m/s; Suitable for application in cafeteria,

bakery, waiting room, restaurants, retail shop, department store, sports center and so on.

Specifications:

Model

Size

(mm)

Volt./ Freq.

Motor

power(W)

Air volume

(m3/h)

Air speed

(m/s)

Noise

(dB)

N.W(kg)

Hi

Lo

Hi

Lo

Hi

Lo

FM-1206SA1

600x180x215

220v~

50Hz

140

90

840

680

9-11

55

54

8.5

FM-1209SA1

900x180x215

160

110

1400

1100

57

55

10.5

FM-1210SA1

1000x180x215

180

130

1600

1300

58

56

11.5

FM-1212SA1

1200x180x215

200

150

1900

1600

58

56

13.5

FM-1215SA1

1500x180x215

230

180

2500

2000

59

57

15

FM-1218SA1

1800x180x215

300

250

3200

2600

60

58

20

FM-1220SA1

2000x180x215

350

300

3600

2900

61

59

22

What is Air Curtain?

Theodoor Air curtain is installed above the entryway of store, restaurant, hotel...etc. It can effectively isolate convection indoor and outdoor and keep temperature and humidity. Especially used in the location with air conditioner to keep indoor environment and save energy of refrigeration equipment. In addition, Air Curtain can prevent the invasion of dust, pest and harmful fumes from outside. In this way, a comfortable indoor climate is maintained.
