Specifications
MOQ :
10
Price :
$1,399
Voltage :
220V
Fan diameter :
148mm
Motor power :
0.85-1.70kW
Max air velocity :
18-73m/s
Noise level :
64-73dB
Air volume :
6790-13580m3/h
Weight :
57-113kg
Width :
480mm
Depth :
330mm
Height :
2000-4000mm
Material :
SS304 stainless steel
Motor type :
High-performance
Fan type :
Centrifugal turbine
Installation type :
Vertical
Suitable entrance width :
3-4m
Description

Product Description

Products feature:

Vertical Air Curtain with stainless steel cabinet design won’t be rusty and discoloration;

High grade with elegant appearance;

Adopting high-performance motor, safe and reliable; Centrifugal turbine creates higher air velocity;

Suitable for installation in luxury hotel, supermarket chains, large stadiums and airport terminals and other

entrances require vertical installation.

Model

Voltage

(V~)

Fan Dia.

(mm)

Motor power (kW)

Max air velocity

(m/s)

Noise (dB)

Air volume

(m3/h)

Weight (Kg)

Dimension

(mm)

FM-LC2000S

220

148

0.85

18

64

6790

57

480x330x2000

FM-LC2500S

1.10

65

8450

70

480x330x2500

FM-LC3000S

1.25

67

10230

85

480x330x3000

FM-LC3500S

1.55

70

11860

102

480x330x3500

FM-LC4000S

1.70

73

13580

113

480x330x4000

SS304 Vertical Air Curtain for 3-4m Entrances 18m/s AirflowSS304 Vertical Air Curtain for 3-4m Entrances 18m/s Airflow

SS304 Vertical Air Curtain for 3-4m Entrances 18m/s Airflow

Company information
SS304 Vertical Air Curtain for 3-4m Entrances 18m/s AirflowSS304 Vertical Air Curtain for 3-4m Entrances 18m/s AirflowSS304 Vertical Air Curtain for 3-4m Entrances 18m/s AirflowSS304 Vertical Air Curtain for 3-4m Entrances 18m/s AirflowSS304 Vertical Air Curtain for 3-4m Entrances 18m/s Airflow
Why Choose Us?

Experience: More than 22 years manufacture & export experience. More than 100 models air curtain, suitable for different environments.

Engineer: Professional R&D and engineer teams focus on Air curtain.

Machinery & technology: Advanced mould machines and equipments ensure products performance and reliability.

Materials and Quality: At every stage, from raw materials to the end products we insist on results: safety, efficiency, energy conservation and environmental protection, and our rigorous testing ensures that we reach standards higher than similar products. We want consumers to depend on the precision and reliability of our Air Curtain machinery.

Quality control: 100% product performance testing.

Cost saving: We provide long-life and high reliability air curtains with excellent quality and better performance, resulting in increased cost saving

Feedback customers queries promptly: Customers are always given quick support.
