0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
Specifications
Brand Name :
THLB
Model Number :
6.4V 1.8Ah LiFePO4 Battery pack
Place of Origin :
China
MOQ :
10 pieces
Price :
$2.70/pieces 10-49 pieces
Packaging Details :
Standard Packaging
Delivery Time :
15-20 Working Days
Payment Terms :
T/T
Battery Size :
18650
Application :
Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS
Weight :
90g
Type :
lifepo4
Voltage :
6.4V
Capacity :
1.8Ah
Category :
Rechargeable Batteries pack
Cycle Characteristic :
1500 times
Working Temperature :
-20°C~60°C
PCB :
yes
Package :
pvc
Anode Material :
LFP
The charging ratio :
0.5C
The discharge rate :
1C
Description
0.5C LiFePO4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
Charging Ratio 0.5C LiFePO4 Battery Pack 6.4V 18650 2S1P 1.8Ah Rechargeable Small Emergency Light Lithium Ion Battery
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
Product Components
Main Kit Includes 1 x 6.4V 1.5Ah LiFePO4 Battery Module 1 x 2S-3A PCM 1 x Molex 5557-2P
Technical Specifications
Specification Value
Normal Voltage 6.4V
Normal Capacity 1.8Ah
Battery Energy 9.6Wh
Inner Resistance < 20mΩ
Battery Cycle Life 2000 Times @100% DOD
6000 Times @80% DOD
Cell Configuration LiFePO4 18650 3.2V 1800mAh - 2S1P
Reference Battery Size (φ18.6±2)mm × (135±2)mm
Reference Battery Weight 88±2g
Battery Encapsulation PVC
Operation Temperature Range Charge: 0°C - 45°C
Discharge: -20°C - 60°C
Battery Storage Temperature -20°C - 25°C
Individual Cell Approval CE / RoHS / UN38.3 / UL 1642 / IEC 62133 / CB / KC / BIS
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
Safety Performance Classification
  • Resistance to heavy loads - Tested to not ignite or explode
  • Resistance to thermal shock - Tested to not ignite or explode
  • Anti-overcharge - Tested to not ignite or explode
  • Resistance to overdischarge - Tested to not ignite or explode
  • Resistance to short circuit - Tested to not ignite or explode
  • High temperature storage - Tested to not leak, smoke, catch fire or explode
  • Anti-heating - Tested with no battery penetration through screen
  • Anti-puncture - Tested to not ignite or explode
  • Anti-extrusion - Tested to not ignite or explode
  • Resistance to low pressure - Tested to not leak, smoke, catch fire or explode
  • Constant damp heat - Maintains capacity ≥90% of rated value after testing
  • Anti-vibration - Maintains normal operation after testing
  • Anti-collision - Maintains normal operation after testing
  • Temperature cycling - Maintains capacity ≥70% of initial state after testing
  • Flame retardant properties - Meets GB/T2408-2008 FH-1 and FV-0 requirements
  • Insulation resistance - ≥2 MΩ for metal case batteries
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah 0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
Our Company
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
Packing & Delivery
0.5C Lifepo4 Battery Pack 18650 2S1P Emergency Light Lithium Battery 6.4V 1.8Ah
Frequently Asked Questions
Q1. Can I have few free samples for evaluation?
A: Yes, free samples are ok, but not covering shipping cost
Q2. What about the lead time?
A: Samples needs 3-5 days
B: Mass production time is approx 2-3 weeks
Q3. Do you have any MOQ limit for bulk order?
A: MOQ=100pcs
Q4. How do you ship the goods and how long does it take to arrive?
A: Samples and small quantity trial order: Courier shipping with door to door; normally 6-10 days
B: Big quantity bulk order: Air shipping or Sea shipping
Q5. How to proceed an order for Lithium ion cell?
A: Pls confirm the cell models that you are interested in
B: We send cell specifications and best quotation to you for reference
C: You confirm the quotation and inform quantity or issue PO, we will send PI accordingly
D: After deposit or full payment confirmed, production started
Q6. Is it OK to print my logo on lithium ion cell product?
A: Yes. OEM is welcomed
Q7: Do you offer guarantee for the products?
A: Yes, 3-5 Years Warranty
