TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register
TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register
TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register
TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register
TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register
TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register
Specifications
Brand Name :
HETECH
Model Number :
HC050TG30029-D12
Certification :
ISO9001,ISO14001,ISO13485,IATF16949
Place of Origin :
China
MOQ :
100pcs
Payment Terms :
T/T
Supply Ability :
50K/month
Delivery Time :
4-6weeks
P/N :
HC050TG30029-D12
Size :
5"(TN)
Display type :
(TN)
Resolution :
800*480
Outline dimension :
120.7(W )*75.8(H)*3.1(T)mm
Active area :
108(W)*64.8(H)mm
Brightness :
300cd/m2
Interface :
50pinRGB
Viewing angle :
70/70/50/70
Driver IC :
ILI5960&ILI6122
Operation Temp. :
-20~70
Storage Temp. :
-20~70
Contrast ratio :
500
Aspect rati16:9o :
16:9
Application :
multi function MIG welding machine, video brochure, cash register
Description

5 inch TFT LCD display with 500:1 Contrast Ratio for Cash Register

Product Description:

HC050TG30029-D12 is a 5-inch TN display module with a resolution of 800*480 pixels, which is designed to bring an excellent visual interaction to the public. 300nits brightness and 500:1 contrast ratio not only ensure image quality and viewing experience, but also have good energy-saving effects. This display is designed with a 50pin RGB interface, which supports stable data transmission and high quality image presentation. Besides, this display can maintain good operating conditions at temperatures from -20°C to 70°C, and its performance will not be affected in complex environments. The HC050TG30029-D12 has an active area of 108.00mm*64.80mm and its outline dimension is 120.70mm*75.80mm*2.9mm, which enables this display to be perfectly used in multi function MIG welding machine, video brochure, cash register etc.


General Specification:

P/N
HC050TG30029-D12
Size 5inch
Display type
Normally White, Transmissive LCD
Resolution 800*480
Outline Dimension(mm) 120.7(W )*75.8(H)*3.1(T)mm
Active Area(mm) 108(W)*64.8(H)mm
Brightness(cd/m²) 300
Viewing Angle(L/R/T/B) 70/70/50/70
Interface 50pinRGB
Operation Temperature -20~70
Storge Temperature -20~70
Aspect ratio 16:9
Contrast ratio 500
Application multi function MIG welding machine, video brochure, cash register

Pin assignment:

TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register

Product drawings:

TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register

5-inch lcd display series:

5-inch LCD Display Sizes
Warm reminds:if models listed below can't meet your requirements,customization can be made according to your specific requirements but it is not limited to LCM,RTP,CTP,driver board.etc.
No. Size Part No. LCD type Resolution Outline dimension Active area Interface Contrast ratio Brightness Operation temperature Storage temperature
1 5" HC050IG25031-B04V01 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 1000 250 -20~70℃ -30~80℃
2 5" HC050IG40031-B04V01 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 1000 400 -20~70℃ -30~80℃
3 5" HC050IG50031-B04V01 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 1000 500 -20~70℃ -30~80℃
4 5" HC050IG80031-B04V03 IPS 800*480 120.7*75.8*3.1mm 108*64.8mm 40pinRGB 1000 800 -20~70℃ -30~70℃
5 5" HC050IG80031-B04V05 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 1000 1000 -30~85℃ -30~85℃
6 5" HC050IGA0031-B04 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 1000 1000 -30~85℃ -30~85℃
7 5" HC050IGA5031-B04 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 1000 1500 -20~70℃ -30-80℃
8 5" HC050IGB0031-B04 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 1000 2000 -20~70℃ -30-80℃
9 5" HC050IG35031-B04 IPS 800*480 120.7×76.4×3.1mm 108*64.8mm 50pinRGB 800 350 -20~70℃ -20~70℃
10 5" HC050IG40031-B04 IPS 800*480 120.7*75.8*3.1mm 108*64.8mm 40pinRGB 1000 400 -20~70℃ -30-80℃
11 5" HC050IG40031-B04V.C IPS 800*480 127.0*85.8*4.8mm 108*64.8mm 40pinRGB 1000 350 -20~70℃ -20~70℃
12 5" HC050IG50031-B06V01 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 50pinRGB 1000 500 -20~70℃ -30-80℃
13 5" HC050IG40031-B06V01 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 50pinRGB 1000 400 -20~70℃ -30-80℃
14 5" HC050IG40029-D58 IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 20pinLVDS 1000 400 -20~70℃ -30-80℃
15 5" HC050IG40029-D58V.C IPS 800*480 130.70*85.80*4.68mm 95.04*53.856mm 20pinLVDS 1000 300 -20~70℃ -30-80℃
16 5" HC050IGA0031-B08H IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinLVDS 1000 1000 -20~70℃ -20~70℃
17 5" HC050IGA3070-F22 IPS 800*480 121*78.8*7mm 108*64.8mm 50pinRGB 1000 1300 -30~85℃ --30~85℃
18 5" HC050IG30029-F41V.C IPS 800*480 120.7*75.8*2.9mm 108*64.8mm 12pinRGB 1000 300 -20~70℃ -30~80℃
19 5" HC050IV60016-B17 IPS 1080x1920 64.5x117.7x1.6mm 61.641*109.584mm 34pinMIPI 1000 600 -20~60℃ -30~70℃
20 5" HC050IV60016-B17 V.C IPS 1080x1920 64.5x117.7x1.6mm 61.641*109.584mm 34pinMIPI 1000 600 -20~60℃ -30~80℃
21 5" HC050TG25031-27 TN 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 500 250 -20~70℃ -30~80℃
22 5" HC050TG25031- 27V01 TN 800*480 120.7*75.8*3.1mm 108*64.8mm 40pinRGB 500 250 -20~70℃ -20~70℃
23 5" HC050TG40031-27 TN 800*480 120.7*75.8*2.9mm 108*64.8mm 40pinRGB 500 250 -20~70℃ -30~80℃
24 5" HC050TG30029-D12 TN 800*480 120.7*75.8*2.9mm 108*64.8mm 50pinRGB 500 300 -20~70℃ -30~80℃
25 5" HC050TGA0029-D12 TN 800*480 120.7*75.8*2.9mm 108*64.8mm 50pinRGB 500 1000 -20~70℃ -30~80℃
26 5" HC050IG30029-F41 IPS 800*480 120.7*76.3*4.75mm 108*64.8mm 12pinSPI 1000 300 -20~70℃ -30~80℃
27 5" HC050TG50029-D12 TN 800*480 120.7*75.8*2.9mm 108*64.8mm 50pinRGB 500 500 -20~70℃ -30~80℃


Customization:

TN Type 5 Inch TFT LCD Screen With ILI5960 ILI6122 Driver IC For Cash Register

FAQ:
Q1. Can I have a sample order for LCD Display
A: Yes, we welcome sample order to test and check quality
Q2. What about the lead time?
A: Usually 4~5 days for sample orders if goods are in stock, and 4~6 weeks for mass production (basing on the quantity and product).
Q3. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx.
Q4. How to proceed an order for LCD Display?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q5: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
Q6: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
B.Besides danmage caused by human factors, within one year warranty from the start of shipping.
If there are special conditions, the warranty time will be separately notified.
