Specifications
Brand Name :
KOE
Model Number :
TX16D20VM5BAA
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Supply Ability :
500PCS
Packaging Details :
STANDARD PACKING
Delivery Time :
2-3 DAY
MODEL NUMBER :
TX16D20VM5BAA
BRAND :
KOE
SIZE :
6.2 inch
RESOLUTION :
640(RGB)×240, HVGA, 109PPI
BRIGHTNESS :
400 cd/m² (Typ.)
TEMPERATURE RANGE :
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
Description

KOE TX16D20VM5BAA Summary

TX16D20VM5BAA is a 6.2" diagonal a-Si TFT-LCD display panel product from Kaohsiung Opto-Electronics Inc. (hereafter called KOE), with an integral WLED backlight system, without backlight driver, without touch screen. It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 2.0G (19.6 m/s²).

KOE TX16D20VM5BAA Application Details

Basic Detail : Manufacturer Model Name TX16D20VM5BAA
Panel Type a-Si TFT-LCD , LCM Another Name -
Panel Size 6.2 inch Designed For
Maximum Ratings : OP Temperature -20 ~ 70 °C ST Temperature -30 ~ 80 °C
Vibration Level 2.0G (19.6 m/s²) RoHS
Features :
Remarks : IPS-Like

KOE TX16D20VM5BAA Optical Details

Basic Information : Luminance 400 cd/m² (Typ.) Contrast Ratio 400 : 1 (Typ.) (Transmissive)
Good View at - Response Speed 45 (Typ.)(Tr+Td) (ms)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10) Operating Mode TN, Normally White, Transmissive
Color Performance : Chromaticity Wx:0.290; Wy:0.310 Support Color 262K (6-bit)
Color Temperature 8266K White Uniformity 1.33 (Max.)(9 points)
1931 Color Gamlt : NTSC Ratio 61% sRGB 80% coverage
Adobe RGB 63% coverage DCI-P3 63% coverage
Rec.2020 45% coverage Remarks sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

KOE TX16D20VM5BAA Mechanical Details

Pixel Features : Number of Pixel 640(RGB)×240 [HVGA] Arrangement RGB Vertical Stripe
Dot Pitch(W×H) 0.0775×0.224 mm Pixel Pitch(W×H) 0.2325×0.224 mm [109PPI]
Physical Size : Active Viewing 148.8(W)×53.76(H) mm Overall Dim. 173(W)×70(H) mm
Bezel Opening 152.8(W)×57.76(H) mm Overall Depth 7.0 (Max.) mm
Outline Features : Form Shape Flat Rectangle Orientation Landscape type
Aspect Ratio(W:H) 8:3 Shape Style
Fixation : Without
Other Detail : Mass 100g (Typ.) Surface Antiglare

KOE TX16D20VM5BAA Electronics Details

Refresh Rate : 60Hz
Reverse Scan : No

KOE TX16D20VM5BAA Interface Details

Signal Electrical : Input Current 200/280mA (Typ./Max.) Input Voltage 3.3V (Typ.)
Consumption 0.31W (Typ.) Signal Interface CMOS (1 ch, 6-bit)
Interface Features : Position - Physical Type Connector
Signal Interface : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JAE FA5B040HP1 1 pcs 0.5 mm 40 pins

KOE TX16D20VM5BAA Lightting Details

Lamp Features: Lamp Shape Array Lamp Type WLED Position Edge light type
Exchange - Amount 3S7P Life 40K(Typ.) (Hours)
Lamp Electrical : Input Current 84.0/95.0mA (Typ./Max.) Input Voltage 12.0±0.5V
Consumption 1.01W
Interface Features : Position - Physical Type Connector
Interface Detail : Brand Model Amount Pin Pitch Pin Amount Pin Assignment
JST BHR-03VS-1 1 pcs 4.0 mm 3 pins BLE-3PINS-ANC
Backlight Driver : No
