T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
T-51440GL070H-FW-AF Kyocera 7INCH LCM 480×234RGB 400NITS CCFL INDUSTRIAL LCD DISPLAY
Specifications
Brand Name :
Kyocera
Model Number :
T-51440GL070H-FW-AF
Certification :
ISO9001
Place of Origin :
JAPAN
MOQ :
1PCS
Payment Terms :
TT/PAYPAL/WESTERNUNION/ESCROW
Supply Ability :
100PCS
Delivery Time :
1-2day
Packaging Details :
STANDARD PACKING
BRAND :
Kyocera
MODEL NUMBER :
T-51440GL070H-FW-AF
SIZE :
7INCH
RESOLUTION :
480×234RGB
BRIGHTNESS :
400 cd/m² (Typ.)
Light Source :
CCFL [1 pcs] , 20K hours , With Inverter
Interface Type :
TFT Specific Analog RGB , 30 pins
TEMPERATURE RANGE :
Operating Temperature: -30 ~ 75 °C
Description

PTREX T-51440GL070H-FW-AF Application Features

Basic Information : Manufacturer Panel Model Panel Type Alias
T-51440GL070H-FW-AF a-Si TFT-LCD , LCM -
Environment : RoHS State Operating Temp. Storage Temp. Vibration Level
- -30 ~ 75 °C -40 ~ 85 °C -
Used For :

OPTREX T-51440GL070H-FW-AF Optical Features

Basic Information : Luminance (cd/m²) Viewing Angle (L/R/U/D) Response Time (ms)
400 (Typ.) 60/60/30/60 (Typ.)(CR≥10) 10/20 (Typ.)(Tr/Td)
Best View on Display Mode Contrast Ratio
6 o'clock TN, Normally White, Transmissive 150 : 1 (Typ.) (Transmissive)
Dispaly Color : Color Temperature Display Colors White Coordinate
4867K Full color X:0.350; Y:0.365

OPTREX T-51440GL070H-FW-AF Mechanical Features

Panel Size : 7.0"
Pixel Features : Pixel Format Pixel Configuration Pixel Pitch (mm) Dot Pitch (mm)
480(RGB)×234 RGB Vertical Stripe 0.321×0.372 [76PPI] 0.107×0.372
Mechanical Size : Active Area (mm) Bezel Area (mm) Outline Dimension (mm) Outline Depth (mm)
154.08(H) × 87.05(V) - 164.9(H) × 101.9(V) 23.1 (Typ.) mm
Outline Features : Form Factor Orientation Aspect Ratio Shape Style
Flat Rectangle Landscape type 16:9 (H:V)
Other Detail : Weight Panel Cover Treatment
300g (Max.) - -

OPTREX T-51440GL070H-FW-AF Electronics Features

Reverse Scan : Yes (U/D, L/R)
Vertical Frequency : 60Hz
Time Controller (T-CON) : Need external T-CON

OPTREX T-51440GL070H-FW-AF Backlight Features

Lamp Features: Type Position Quantity Shape Life(Hours) Lamp Exchange
CCFL Edge light type 1 pcs - 20K(Min.) -
Interface Features : Position Backlight Driver Type
- With Inverter Included in panel signal interface
Driver Electrical : Voltage Supply Current Supply Power Consumption
12.0V (Typ.) - 4.2W (Typ.)

OPTREX T-51440GL070H-FW-AF Interface Features

Panel Driving Electrical : Voltage Supply Current Supply Power
12.0V (Typ.) - 2.4W (Typ.)
Detail : Brand Model Pin Pitch Pin Amount Quantity Configuration
30 pins 1 pcs

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
